50-800x Long Working Distance Trinocular Head Inverted Optical Microscope CE A14.0301
Specification
|
A14.0301 Biological Microscope Specification
|
B
|
T
|
Head
|
Binocular Head, inclined 30°, interpupillary distance 55-75mm
|
●
|
|
Trinocular Head, inclined 30°, interpupillary distance 55-75mm
|
|
●
|
Eyepiece
|
WF10x/18mm
|
●
|
●
|
WF16x/11mm
|
●
|
●
|
Nosepiece
|
Quadruple nosepiece
|
●
|
●
|
Objective
|
Long Working Distance Plan Achromatic 4x/0.1, W.D.=17.4mm
|
●
|
●
|
Long Working Distance Plan Achromatic 10x/0.25, W.D.=8.0mm
|
●
|
●
|
Long Working Distance Plan Achromatic 20x/0.40, W.D.=5.0mm
|
●
|
●
|
Long Working Distance Plan Achromatic 40x/0.6(S), W.D.=3.0mm
|
●
|
●
|
Auxiliary objective 1.25x
|
●
|
●
|
Thickness in the bottom of culuture ware 1.5mm
|
●
|
●
|
Working Stage
|
Mechanical stage size 190x145mm, moving range 75x50mm, minimum vernier division 0.1mm
|
●
|
●
|
Focusing
|
Coaxial coarse & fine focusing knob, coarse focusing range 30mm, fine focusing division 0.002mm
|
●
|
●
|
Filter
|
Yellow filter Φ43mm
|
●
|
●
|
Green filter Φ43mm
|
●
|
●
|
Light
|
12V 50W Halogen lamp, brightness adjustable
|
●
|
●
|
|
Optional Accessories
|
Item No.
|
Adapter
|
CCD adapter
|
A55.0302
|
Photo adapter
|
A55.0301
|
Digital camera adapter
|
A55.0303
|
|
