Halogen Lamp Inverted Optical Microscope Wide Field Microscopes CE A14.1101

Halogen Lamp Inverted Optical Microscope Wide Field Microscopes CE A14.1101

  • High Light

    inverted fluorescence microscope

    ,

    inverted light microscope

  • Applications
    Research
  • Certification
    CE, Rohs
  • Drawtube
    Binocular, Trinocular
  • Illumination
    Halogen Lamp
  • Product Name
    Inverted Optical Microscope
  • Theory
    Inverted Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A14.1101
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Halogen Lamp Inverted Optical Microscope Wide Field Microscopes CE A14.1101



Halogen Lamp Inverted Optical Microscope Wide Field Microscopes CE A14.1101



Specifications:



A14.1101 Inverted Metallurgical Microscope Specification

-A

-B

-C

-D

Head

Compensation Free Binocular,45°inclined,50mm-75mm

-

-

Compensation Free Trinocular,45°inclined,50mm-75mm

-

-

Eyepiece

Wide field WF10X/20mm

-

-

Wide field WF10X/23mm

-

-

Long Working Distance Plan-Objective

LWDPL 4X/0.1 W.D. 25mm

-

-

LWDPL 10X/0.25 W.D. 11mm

-

-

LWDPL 20X/0.4 W.D. 8mm

-

-

LWDPL 40X/0.6 W.D. 3.8mm

-

-

Infinity Long Working Distance Objective

LWDPL 4X/0.1 W.D. 25mm

-

-

LWDPL 10X/0.25 W.D. 12mm

-

-

LWDPL 20X/0.4 W.D. 10mm

-

-

LWDPL 40X/0.6 W.D. 7mm

-

-

Long Working Distance Phase Contrast Objective

LWDPL 20X

Focus System

Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm.

Nosepiece

Quadruple

-

-

Quintuple

-

-

Condenser

N.A.0.3 ABBE Condenser,W.D.75MM

Phase Contrast Sliding Plate

Center of Phase Contrast Ring Plate Adjustabel

Centering Telescope

Centering Telescope

Filter

Blue Filter

Green Filter

Yellow Filter

Frosted Glass

Stage

Double Layer Mechanicall, Central Stage: Φ110mm (Size242mmX172mm,Moving Range:75mmX50mm)

Light Source

Halogen Bulb,12V/30W,Adjustble Brightness

Optional Accessories

Eyepiece

Wide field WF10X/18mm with Crosshair Graduation of 0.1mm Scale

Long Working Distance Phase Contrast Objective

LWDPL 10X

LWDPL 40X

Fluorescence Attachment

B Wave Band

G Wave Band

220V/110V/100W Mercury Lamp

Photograph Attachment

Photography Connecting Tube,Adapter with MD or PK Mount,4X Photography Eyepiece
