School USB LCD Forensic Comparison Microscope With Android System A18.1845-LCD

School USB LCD Forensic Comparison Microscope With Android System A18.1845-LCD

  • High Light

    transmitted light microscope

    ,

    bullet comparison microscope

  • Applications
    Student|school|Laboratory
  • Certification
    CE|Rohs
  • Drawtube
    Binocular
  • Illumination
    LED
  • Magnification
    2.5x - 160x
  • Theory
    Comparison Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A18.1845-LCD
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

School USB LCD Forensic Comparison Microscope With Android System A18.1845-LCD

Quick Detail:


9.7'' LCD Pad Digital Camera, Android System
★ Total Magnification 2.5x~160x
★ Wide Field Eyepiece WF10x/22mm, WF20x/12mm, High Eyepoint
★ 5 Step Zoom Plan Objective 0.64x, 1.0x, 1.6x, 2.5x, 4.0x
★ Auxiliary Lens 0.4x and 2.0x Included
★ Full left/right, split-image or overlapping image comparision
★ Magnification Correcting System, with Correcting Lens
★ Separation Line Adjusting System, with Special Designed Metal Adjust Driver
★ 5W LED Warm & Cold Light, High Brightness, Brightness Adjustable
★ All Light Source Brightness Adjustable, Position & Angle Adjustable Freely
★ Full Range Light Source Accessories Included, Coaxial Light, Polarizing Light, Ultraviolet Lens,
★ Red/Blue/Green/Yellow Filters
★ 80~240V Wide Range Voltage



Description:

A18.1845-LCD Forensic Comparison Microscope, newly developed in 2013, is suitable to be used for forensic science education & school, to give an idea and training to the students what is a comarison microscope and learn how to use it. It is simple but including full comparison system function, and with steady quality at very competitive price!


Applications:

It is primarily designed for school students to do image analysis and distant sharing.
This unique combination of microscope, image system and software makes it a professional tool for education
applications.This microscope also provides a superior cost effective solution for computer interactive laboratory,
clinical environments and etc.


Specifications:



A18.1845-LCD Forensic Comparison Microscope Specification

LCD Pad

9.7'' LCD Pad Digital Camera, Android System,
5.0 M Pixels, Full Resolution 2592*1936
1* Mini USB2.0, 1*HDMI, 1* Micro-SD Card Slot (Up to 32GB), 1* 3.5mm Standard Stereo Earphone Slot,1* SIM Card Slot
Details see A59.3503

Magnification

2.5x-160x

Head

Bionocular Head, 30° Incline, Interpupilary Distance 50~75mm, Diopter +/-5 Adjustable

Eyepiece

WF10x/23mm, High Eyepoint

WF20x/12mm, High Eyepoint

Objective

5 Step Zoom Plan Objective 0.64x, 1.0x, 1.6x, 2.5x, 4.0x

Auxiliary Lens 0.4x, 2.0x

Working Distance

100mm

View Field

Dia. 2.0~90mm

Magnification Correcting

Magnification Correction System, with Correcting Lens

Separation Line Adjusting

Seperation Line Adjust System in Back, with Special Designed Adjust Driver

Working Stage

Square Manual Working Stage 100*100mm, Moving Range 54*54*54mm

Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable

Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm

Light Source

5W LED Warm Light, High Brightness, Brightness Adjustable

5W LED Cold Light, High Brightness, Brightness Adjustable

Coaxial Light Lens, to observe in deep hole, or smooth object surface

Polarizing Light Lens, to eliminate flare lights and dazzling lights;

Transmit Bottom Light

Ultraviolet Light Lens

Filters: Red, Blue, Yellow, Green

Adapter

CCD Adapter

Photo Adapter for SLR Digital Camera

Power

80~240V Wide Range Voltage

Dimension

Instrument Size 38*31*85cm





Competitive Advantage:

Comparison Microscope, Forensic Microscope, Bullet Microscope, LCD Forensic Comparison Microscop


High quality optical system, and optical components coated with special coating

created a high-quality optical system.

■Standard magnification 7X~45X. Use optional auxiliary lens, the magnification

can be 3.5X~180X

■ Long working distance to create enough space for the uses

■ Suit to ergonomic design, feel less fatigue when long time use.
