400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202

400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202

Products - Inverted Optical Microscope
  • Highlight

    inverted biological microscope

    ,

    inverted fluorescence microscope

  • Applications
    Laboratory|Research
  • Certification
    CE|Rohs
  • Drawtube
    Trinocular
  • Illumination
    Halogen Lamp
  • Product Name
    Inverted Optical Microscope
  • Theory
    Inverted Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A14.0202
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202

  • 400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202
  • 400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202
  • 400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202
  • 400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202
Get Price Contact Now

400X Plan Phase Contrast  Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202

A14.0202 Inverted Phase Contrast Microscope is equipped with wide field eyepieces, long working distance plan achromatic objectives, long working distance condenser and phase contrast unit. It can observe transparent and unfinished living specimen in culture bottle or culture utensil. It is the ideal tools for research of living specimen structure, liquid, deposits and so on.
--Wide Field Eyepiece WF10x/20
--Sliding Phase Contrast Included
--Coaxial Coarse/Fine Focus System, Minimum Division 0.002mm
--Halogen Lamp 6V 20W With Brightness Control




A14.0202 Inverted Phase Contrast Microscope
MagnificationTotal 100~400x
HeadTrinocular Head, 30° Inclined, 100 Ligh Pass For Photography
Eyepiece

WF10x/20mm Wide Field

NosepieceQuadruple
ObjectiveLWD Plan Achromatic Objective
PLL10x/0.25, W.D.8.8mm
PLL 25x/0.40, W.D.4.8mm
PLL 40x/0.60, W.D.3.3mm
LWD Plan Phase Contrast Objective
PLL10x/0.25 PHP2, W.D.8.1mm
Working StageDouble Layer Mechanical Stage 224*208mm, Moving Range 112*79mm
Culture Dish Holder, For Dia.68mm Or 77*29mm Culture Utensil
Culture Dish Holder, For 82*57mm Culture Utensil
Culture Dish Holder, For 128*85mm 96 Holes Culture Utensil
FocusingCoaxial Coarse & Fine Focus Knob, With Tension Adjustable And Limit Stopper, Minimum Division 0.002mm
CondenserLong Working Distance Phase Contrast Condener,
N.A.0.4, Working Distance 50mm, Rack & Pinion Adjustable
Sliding
Phase Contrast		Sliding Phase Plate 10x
Centering Telescope Eyepiece 10x
FilterBlue, Green, Frost Filter
Light SourceKohler Illumination, 6V30W Halogen Lamp, Brightness Adjustable
Optional Accessories
EyepieceWF16x/11mmA51.0203-16A
Dividing Eyepiece 10x/20mm, 0.1mm/DivA51.0205-G10A
Sliding Phase ContrastLWD Plan Phase Contrast ObjectivePLL25x/0.40 PHP2, W.D.4.78mmA5C.0232-25a
PLL40x/0.60 PHP2, W.D.3.32mmA5C.0232-40a
Ultra Long Working Distance Phase Contrast Condener,
N.A.0.4, Working Distance 70mm		A5M.0210-6
Sliding Phase Contrast Plate 25x/40xA5C.0211-5
FilterYellow FilterA56.0209-3
AdapterCCD Adapter 0.5xA55.0202-04
Digital SLR Camera Adapter for Canon EF SeriesA55.0204-02


400X Plan Phase Contrast Inverted Optical Microscope Halogen Lamp Rohs CE A14.0202 0
