OPTO-EDU Stereo Microscope with Large Zoom Lens 0.6x-5.5x, Zoom Ratio 1:9.1, and 125 mm Working Distance for Life Sciences & Industrial Inspection
-
Highlight
Large Zoom Lens 0.6x-5.5x Stereo Microscope
,Zoom Ratio 1:9.1 Stereo Optical Microscope
,125 mm Working Distance Stereo Zoom Microscope
-
Place of OriginChina
-
Brand NameCNOEC, OPTO-EDU
-
CertificationCE, Rohs
-
Model NumberA23.1017A23.1019
-
Document
-
Minimum Order Quantity1 pc
-
PriceFOB $1~1000, Depend on Order Quantity
-
Packaging DetailsCarton Packing, For Export Transportation
-
Delivery Time5~20 Days
-
Payment TermsT/T,West Union,Paypal
-
Supply Ability5000 pcs/ Month
OPTO-EDU Stereo Microscope with Large Zoom Lens 0.6x-5.5x, Zoom Ratio 1:9.1, and 125 mm Working Distance for Life Sciences & Industrial Inspection
OPTO-EDU A23.1017/A23.1019 Stereo Microscopes
Key Features
- Infinity-Corrected Apochromatic Optical System
- Large Zoom Lens 0.6x-5.5x, Zoom Ratio 1:9.1
- Oblique Light & Transmit LED Illumination
- Complete Accessories Include Polarizing, Dark Field
- Standard Plan APO Lens
The A23.1017/A23.1019 series stereo microscopes feature a groundbreaking apochromatic optical system, delivering superior performance in resolution, depth of field, contrast, and color fidelity. With a 125mm working distance, these microscopes provide a safe and spacious operating environment for both live specimen manipulation and industrial inspection.
Exceptional Imaging Quality
Equipped with an apochromatic optical system, the A23.1017/A23.1019 series achieves perfect fusion of high contrast, resolution, and color fidelity, delivering imaging quality that surpasses previous standards.
Ergonomic Design
With a 125mm working distance, the A23.1017/A23.1019 provides ample space for comfortable operation, eliminating the constraints of traditional setups. Users can maintain comfortable posture for extended observation sessions.
Versatile Magnification Range
Featuring an impressive 1:9.1 zoom ratio, the A23.1017/A23.1019 offers continuous magnification from 6X to 55X (with 10X eyepieces), enabling effortless switching between wide-field imaging and high-magnification observation.
Multiple Observation Methods
Supports brightfield, darkfield, polarization, and high-contrast imaging, with both binocular and trinocular models available to meet diverse user needs.
Comprehensive Accessory System
Equipped with professional accessories for functional upgrades, catering to needs across basic observation, advanced research, industrial inspection, and education.
Applications
Ideal for life sciences, precision manufacturing, quality control, artifact authentication, and restoration, supporting applications from animal dissection to electronic inspection and cultural relic restoration.
Technical Specifications
| Model | A23.1017-B | A23.1017-T |
|---|---|---|
| Optical System | Infinity-Corrected APOchromatic Optical System | |
| Magnification | 6.7x~50x | |
| Zoom Range | 0.67x~5x | |
| Zoom Ratio | 1:7.5 | |
| Head | Binocular | Trinocular |
| Interpupillary Distance | 50-76mm | |
| Eyepiece | WF10x/23mm, Diopter Adjustable, High Eyepoint, WF15x, WF20x, WF30x (Optional) | |
| Working Distance | 125mm | |
| Illumination | Upper LED 2.4W, Bottom LED 5W | |
| Function | Brightfield, Simple Polarization, Darkfield, Oblique Illumination | |
| Model | A23.1019-B | A23.1019-T |
|---|---|---|
| Optical System | Infinity-Corrected APOchromatic Optical System | |
| Magnification | 6x~55x | |
| Zoom Range | 0.6x~5.5x | |
| Zoom Ratio | 1:9.1 | |
| Eyepiece | WF10x/23mm, Diopter Adjustable, High Eyepoint, WF15x, WF20x, WF30x (Optional) | |
| Head | Binocular | Trinocular |
| Interpupillary Distance | 50-76mm | |
| Working Distance | 125mm | |
| Illumination | Upper LED 2.4W, Bottom LED 5W | |
| Function | Brightfield, Simple Polarization, Darkfield, Oblique Illumination | |
