OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH

Products - Digital LCD Microscope
  • Highlight

    BF+PH LCD Cell Image Inverted Microscope

    ,

    OPTO EDU LCD Cell Image Inverted Microscope

  • Objective
    LWD Infinity Plan FL Semi-APO BF+PH Objectives
  • Phase Contrast Slide
    20x/40x, For Both 20x And 40x
  • Nosepiece
    Quadruple
  • Stage
    Glass Plate, External Diameter Dia.110mm
  • Condenser
    Long Working Distance, N.A.0.32
  • Focusing
    Coaxial Coarse And Fine Focusing Unit
  • Illumination
    5W LED Warm Lamp, Powered By Safety Low Voltage Charger
  • Filter
    Green, Dia.21mm, With Filter Slider
  • Camera
    4K Digital Camera
  • LCD
    11.6" IPS LCD Screen
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A33.2607
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH

  • OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH
  • OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH
  • OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH
Get Price Contact Now
  • Cell Imaging System With High Quality Infinity Corrected Optical System
  • 11.6" Win11 Tablet + 6.3M USB3.0 Digital Camera, or 11.6" LCD + 4K HDMI Digital Camera
  • LWD Infinity Plan Semi-APO Fluorescent BF & PH 4x,10x,20x,40x Objectives
  • LWD Condenser N.A.0.3 Working Distance 72mm, Up To 195mm Without Condenser
  • Working Stage 180x155mm, LWD Condenser N.A.0.32, Transmit 5W LED Koehler Illumination
OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 0

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 1

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 2

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 3

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 4

Objectives In Standard Outfit

LWD Infinity Plan FL Semi-APO Objectives 10x,40x

LWD Infinity Plan FL Semi-APO Phase Contrast Objectives 20x


OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 5

Photo Tube With C-Mount 0.65x

Built-in 0.65x C-Mount In Back of Microscope Body

Triple Layers Mechanical Stage With Glass Plate (Standard Outfit)

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 6

Mechanical Stage 180x155mm

Metal Plate Dia.110mm, Inner Dia.25mm (Optional)

Fixed Stage Size 180x203mm (Optional)

Glass Plate Dia.110mm, Inner Dia.30mm

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 7

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 8
Item Inverted Metallurgical/Biological Microscope Specification A33.2607
-D		 A33.2607
-H		 Order NO.
Digital Camera --11.6" Win11 Tablet, 8G+128G, Image View Measure Software, Support Bluetooth, WIFI, USB3.0, Net.
--6.3M USB 3.0 High Speed 60 FPS Digital Camera		 ●  　 　
HDMI Camera --11.6" IPS LCD Screen, Resolution 1920*1080p
--4K HDMI Digital Camera, Output HDMI+USB+WIFI6 +Net, Built-in Menu For Photo, Video, Measure, Control by Mouse & Keyboard		 　 ●  　
LWD Infinity Plan FL Semi-APO Objectives L Plan FL 4x/0.11                         W.D.=12.1mm ● ● A5F.2635-4
L Plan FL 10x/0.25                        W.D.=10.3mm ○ ○ A5F.2635-10
L Plan FL 20x/0.45                        W.D.=5.8mm ○ ○ A5F.2635-20
L Plan FL 40x/0.65                        W.D.=5.1mm ○ ○ A5F.2635-40
LWD Infinity Plan
FL Semi-APO
BF+PH
Objectives		 For Both Bright Field & Phase Contrast View ○ ○ 　
L Plan FL PHP 4x/0.10                W.D.=9.2mm ○ ○ A5C.2635-04
L Plan FL PHP 10×/0.25                W.D.=10.3mm ● ● A5C.2635-10
L Plan FL PHP 20x/0.45                W.D.=5.8mm ● ● A5C.2635-20
L Plan FL PHP 40x/0.65                W.D.=5.1mm ● ● A5C.2635-40
Phase Contrast Slide   10x ● ● A5C.2611-B10
20x/40x, For Both 20x And 40x ● ● A5C.2611-B2040
Nosepiece Quadruple ● ● A54.2610-N03
Stage Three-layer Mechanical Stage, Size 180x155mm,
Moving Range 75×40mm, Scale 0.1mm,
Round Hole Size Dia.110mm		     A54.2600-01
Fixed Stage, Size 180×203mm,
Round Hole Size Dia.110mm		 ○ ○ A54.2600-02
Glass Plate, External Diameter Dia.110mm, Inside Diameter Dia.30mm ● ● A54.2600-03
Metal Plate, External Diameter Dia.110mm, Inside Diameter Dia.25mm ○ ○ A54.2600-04
Condenser Long Working Distance, N.A.0.32, Working Distance 48mm, With Slide Hole For Phase Contrast Slide ● ● A56.2614-D3
Focusing Coaxial Coarse And Fine Focusing Unit, Coarse Stroke: 10mm, Fine Stroke Per Rotation: 0.2mm, Fine Division 2 μm. ● ● 　
Illumination 5W LED Warm Lamp, Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use ● ● A56.2612-5WP
Filter Green, Dia.21mm, With Filter Slider, or Put on Phase Contrast Slide ● ● A56.2616-21G
Grey, Dia.21mm ○ ○ A56.2616-21N
Blue, Dia.21mm ○ ○ A56.2616-21B
Yellow, Dia.21mm ○ ○ A56.2616-21A
C-mount Built-in C-Mount 0.65x ● ● 　
Packing Size 515x480x315mm, Gross Weight 9kgs, Net Weight 7kgs
Note: "●" Is Standard outfits, "○" Is Optional Accessories.

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 9

OPTO EDU A33.2607 LCD Cell Image Inverted Microscope Semi APO BF+PH 10
