A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x

Products - Stereo Optical Microscope
  • Highlight

    no light source trinocular stereo microscopes

    ,

    7x trinocular stereo microscopes

    ,

    45x opto edu microscope

  • Eyepiece
    WF10x/20mm
  • Zoom Lens
    0.7~4.5x
  • Zoom Ratio
    1:6.5
  • Magnification
    7x-45x, Up To 3.5x-270x With Optional Eyepieces And Auxiliary Objectives
  • Working Distance
    100mm, With Auxiliary Objectives 30~165mm
  • Field Of View
    1~95.2mm
  • Stand
    Pole Stand, No Light Source
  • Place of Origin
    China
  • Brand Name
    OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A23.3645
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x

  • A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x
  • A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x
  • A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x
  • A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x
  • A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x
Get Price Contact Now

0.7-4.5x, Trinocular, WF10x/20, Equipped With Three Wooden Poles And CTV, It Can Connect Ordinary Cameras, Digital Cameras, Industrial Cameras, CCD, B1 Pole Stand + A1 Holder, Stand Size 200*255*22mm, Pole Height 240mm, Dia.32mm, No Light Source, Incl. Eyepiece Adapter

  • Continous Zoom 0.7x-4.5x Binocular & Trinocular Head
  • 7x-45x, Up To 3.5x-270x With Optional Eyepieces & Auxiliary Objectives
  • High Eyepoint, Dia.30mm WF10x/20mm, WF15x, WF20x, WF25x Optional
  • Working Distance 100mm, Up To 30~165mm With Auxiliary Objectives
  • 35 Kinds Stand Optional, Details See A54.3630



A23.3645-B1 Zoom Stereo Microscope Specification B T
Head Binocular Head, 45° Inclined, 360°Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm O 　
Trinocular Head, 45° Inclined, 360°Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm, Eyepiece Tube Adapter 　 O
Eyepiece WF10x/20mm
Zoom Lens 0.7~4.5x
Zoom Ratio 1:6.5
Magnification 7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Objectives
Working Distance 100mm, With Auxiliary Objectives 30~165mm
Field Of View 1~95.2mm
Stand Pole Stand, No Light Source
　
Optional Accessories Cata.No.
Head Binocular Head + WF10x/20mm A53.3645-B
Trinocular Head + WF10x/20mm A53.3645-T
Eyepiece WF10x/20mm, High-eyepoint A51.3621-1020
WF10x/22mm, High-eyepoint A51.3621-1022
WF10x/23mm, High-eyepoint A51.3621-1023
WF15x/15mm, High-eyepoint A51.3621-1515
WF20x/10mm, High-eyepoint A51.3621-2010
WF25x/9mm, High-eyepoint A51.3621-2509
WF30x/8mm, High-eyepoint A51.3621-3008
WF10x/22mm, High-eyepoint, Diopter Adjustable A51.3622-1022
WF15x/15mm, High-eyepoint, Diopter Adjustable A51.3622-1515
WF20x/10mm, High-eyepoint, Diopter Adjustable A51.3622-2010
WF25x/9mm, High-eyepoint, Diopter Adjustable A51.3622-2509
WF30x/8mm, High-eyepoint, Diopter Adjustable A51.3622-3008
Auxiliary Lens 0.5X,W.D. 165mm A52.3621-0.5x
1.5X,W.D. 45mm A52.3621-1.5x
2.0X,W.D. 30mm A52.3621-2.0x
CCD Adapter 1.0x, For CTV A55.3621-1.0x
0.50x, For 1/2" CCD A55.3621-0.5x
0.35x, For 1/3" CCD A55.3621-0.35x
0.50x, For 1/2" CCD A55.3621-N0.5x



























































































































A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 0

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 1

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 2

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 3

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 4

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 5

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 6

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 7

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 8

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 9

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 10

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 11

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 12

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 13

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 14

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 15

A23.3645 Opto Edu Trinocular Stereo Microscopes Magnification 7-45x 16

A23.3645 Zoom Stereo Microscope Optical Data Sheet
Objective Standard 1.0x Auxiliary 0.5X Auxiliary 1.5X Auxiliary 2X
W,D. 100mm 165mm 45mm 30mm
Eyepiece Mag View Field Mag View Field Mag View Field Mag View Field
10X/20mm 7.0X 28.6mm 3.5X 57.1mm 10.5X 19mm 14X 14.3mm
45.0X 4.4mm 22.5X 8.9mm 67.5X 3mm 90X 2.2mm
15X/15mm 10.5X 21.1mm 5.25X 42.8mm 15.75X 14.3mm 21X 10.7mm
67.5X 3.3mm 33.75X 6.7mm 101.25X 2.2mm 135X 1.7mm
20X/10mm 14.0X 14.3mm 7.0X 28.6mm 21.0X 9.5mm 28X 7.1mm
90.0X 2.2mm 45.0X 4.4mm 135.0X 1.5mm 180X 1.1mm
