| A31.0927 |
5M |
12M |
| Head |
Binocular Head, Built-in WIFI Camera, 5MP. |
● |
|
| Binocular Head, Built-in WIFI Camera, 12MP. |
|
● |
| Optical system |
Infinity Color Corrected Optical System |
● |
● |
| Viewing Head |
30° Inclined, Gemel Binocular Head, Interpupillary Distance 47mm-75mm. |
● |
|
| Eyepiece |
PL10x/20mm |
● |
● |
| Nosepiece |
Reversed Quadruple Nosepiece |
● |
● |
| Objective |
Plan Achromatic Objective 4x/0.10, WD=11.9mm |
● |
● |
| Plan Achromatic Objective 10x/0.25, WD=12.1mm |
● |
● |
| Plan Achromatic Objective 40x/0.65, WD=0.36mm |
● |
● |
| Plan Achromatic Objective 100x/1.25, WD=0.18mm |
● |
● |
| Focusing Mechanism |
Low Position Coaxial Focusing Mechanism, Coarse Range: 25mm, Fine Precision: 0.002mm, With Tension Adjustment And Upper Limit |
● |
● |
| Working Stage |
150mmx140mm Mechanical Stage, Moving Range:76mm-50mm, Precision 0.1mm (Triangular Guide Rail) |
● |
● |
| Illumination |
N.A.1.25 Compound Eye Illumination Condenser Group (With Plug-in Phase Contrast And Dark Field Accessories' Interface), Condenser Preset Center, Adaptive 100V-240V Switching Power Supply, Single High Brightness 3W LED Light Intensity Can Be Continuously Adjusted |
● |
● |
