Infinity Inverted Trinocular Metallurgical Optical Microscope A13.2606

China Infinity  Inverted Trinocular Metallurgical Optical Microscope A13.2606 supplier
Infinity  Inverted Trinocular Metallurgical Optical Microscope A13.2606 supplier Infinity  Inverted Trinocular Metallurgical Optical Microscope A13.2606 supplier

Large Image :  Infinity Inverted Trinocular Metallurgical Optical Microscope A13.2606

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A13.2606

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Application: Learning|Metallurgical Certification: CE|Rohs
Drawtube: Trinocular Illumination: Halogen
Magnification: 50X - 500X Theory: Metallurgical Optical Microscope



Infinity Inverted Trinocular Metallurgical Optical Microscope A13.2606





Specification

A13.2606 Inverted Metallurgical Microscope

A
B
Head Seidentopf Trinocular Head, Inclined 45°, interpupilary distance: 48-76mm
Light distribution (both): 100: 0 and 80:20
Eyepiece WF10x/22mm (Diopter Adjustable)
WF10x/22mm (Diopter Adjustable, Reticule 0.1mm)
Metallurgical LWD Infinity Plan Objective 5x/0.13 BF WD=24.23mm
10x/0.25 BF WD=18.48mm
20x/0.40 BF WD=8.35mm
50x/0.70(S) BF WD=1.95mm
5x/0.13 BD WD=24.23

10x/0.25 BD WD=18.48mm

20x/0.40 BD WD=8.35mm

50x/0.70(S) BD WD=1.95mm

Focus System Low positioned, coaxial coarse & fine focusing system, coarse stroke:10mm, fine stroke 0.2mm/rot, minimum reading 2μm
  Quadruple

Nosepiece Quintruple

Stage Three layers,Stage size: 210 mm×180mm, Moving range:50×50mm , Scale : 0.1mm
Polarizing Unit Polarizer & Analyzer
Filter Blue
Illumination 12V/50W Halogen Lamp
Power Supply 110-240V
Optional Accessory

Item No.
Metallurgical LWD Infinity Plan Objective 40x/0.65 BF WD=3.90mm A5M.2633-40A
80x/0.80(S) BF WD=0.85mm A5M.2633-80A
100x/0.90(S) BF WD=1.00mm A5M.2633-100A
80x/0.80(S) BD WD=0.85mm A5M.2633-80B
Filter Green,Amber & Grey A56.2616
Adapter C-Mount Adapter 0.5x (Focus Adjustable) A55.2601-B05A
C-Mount Adapter 1x A55.2601-B1
Digital SLR Camera Adapte For Nikon A55.2622-N
For Sony A55.2622-S
For Canon A55.2622-C
Remark Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
