OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use

OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use

Products - Compound Optical Microscope
  • Highlight

    Dual LED Light Source Student Microscope

    ,

    Digital Screen Compound Optical Microscope

    ,

    Full Metal Body Digital Microscope

  • Body Material
    Solide Strong Full Metal Body
  • Working Stage
    Double Layer Mechanical Stage
  • Focusing
    Coaxial Coarse & Fine Focusing
  • Illumination
    Dual LED, Bottom 1W LED, Top 0.06W LED
  • Power Supply
    AC100-240V Adapter Supply DC 5V1A Power
  • Battery
    18650 Rechargeable Battery 2000 MAH
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A11.3621
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T,West Union,Paypal
  • Supply Ability
    5000 pcs/ Month

OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use

  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
  • OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use
Get Price Contact Now
OPTO-EDU A11.5110 Dual LED Light Source Digital Screen Student Microscope
The 2025 Brand New Design Student Microscope features a super clear optical system with LCD screen on stand, offering exceptional clarity and ease of use for educational settings.
Key Features
  • Built-in Digital Screen Display: Shows stage temperature, battery level, charging status, and top & bottom light indicators
  • Double Layer Mechanical Stage: 95x105mm with X/Y movement (20x50mm)
  • Coaxial Coarse & Fine Focusing for precise adjustments
  • Dual LED Illumination: Upper 0.06W LED + Bottom 1W LED, both with adjustable brightness
  • Power Options: DC 5V1A adapter and 18650 rechargeable battery (2000 mAh, not included for air shipment)
OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 0 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 1 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 2
The A11.5110 Student Microscope includes wide-field eyepieces (WF10X/16mm & WF16X/13mm, Ø23.2mm) and four achromatic objectives: 4x, 10x, 40x(S), and 100X(Spring, Oil). The dual LED illumination (1W bottom, 0.06W top) ensures optimal contrast with low energy use. Designed for durability, the LED boasts a lifespan of up to 50,000 hours, making it a reliable, feature-rich tool for students and educators.
OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 3
Model Specifications
Model A11.5110-M A11.5110-V A11.5110-B A11.5110-T A11.5110-CB A11.5110-CT
Magnification 640X 1600X
Body Material Solid Strong Full Metal Body
Head Monocular, 30° Incline, 360° Rotate Dual Viewing, 30° Incline, 360° Rotate Binocular, 30° Incline, 360° Rotate, Right Diopter Adjustable ±5°, Interpupillary Distance 48-75mm Tinocular, 30° Incline, 360° Rotate, Right Diopter Adjustable ±5°, Interpupillary Distance 48-75mm Seidentopf Binocular, 30° Incline, 360° Rotate, Right Diopter Adjustable ±5°, Interpupillary Distance 48-75mm Seidentopf Tinocular, 30° Incline, 360° Rotate, Right Diopter Adjustable ±5°, Interpupillary Distance 48-75mm
Photo Adapter - Built-in 0.5x C-Mount - Built-in 0.5x C-Mount - Built-in 0.5x C-Mount
Technical Specifications
Eyepiece: WF10x/16mm x1, WF16x/13mm x1 | WF10x/16mm x2, WF16x/13mm x2
Nosepiece: 3 Holes | 4 Holes
Objective: Achromatic 4x, 10x, 40x(S) | Achromatic 4x, 10x, 40x(S), 100x(O,S)
Working Stage: Double Layer Mechanical Stage, 95x105mm, Moving 20x50mm (Upgradeable to heating stage with temperature control function)
Focusing: Coaxial Coarse & Fine Focusing, Fine Division 0.008mm, Coarse Focusing Range 0-15mm
Condenser: - | Abbe Condenser N.A.1.25, With Iris Diaphragm
Illumination: Dual LED, Bottom 1W LED, Top 0.06W LED, Both Brightness Adjustable, Life Time 50000 Hours
Power Supply: AC100-240V Adapter Supply DC 5V1A Power
Battery: 18650 Rechargeable Battery 2000 MAH (NOT Include For Air Shipment)
LCD Panel: Digital LCD Screen On Stand, Display Working Stage Temperature, Battery Level, Charging Status, Top & Bottom LED Light Indicator
Packing Information
Packing List: Power Adapter, Power Cord, 18650 Battery, Instruction Manual, Dust Cover
Weight & Size: Microscope Body 19x14x34cm, Net Weight 2.8Kg
Package (1 Unit): 27x22x40cm, G.W. 3.5Kg
Package (4 Units): 90x29x41cm, G.W. 15Kg
OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 4 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 5 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 6 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 7 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 8 OPTO-EDU A11.5110 Student Microscope with Dual LED Light Source Digital Screen and Full Metal Body for Educational Use 9
