A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope

Products - Biological Microscope
  • Highlight

    Mechanical Stage Biological Microscope

    ,

    Achromatic Binocular Biological Microscope

    ,

    LED Illumination Biological Microscope

  • Head
    Binocular Head, Inclined 30°
  • Eyepiece
    Wide Field Eyepiece WF10x/18
  • Objective
    Achromatic Objective
  • Nosepiece
    Quadruple Nosepiece
  • Focusing
    Coaxial Coarse & Fine Focusing, Fine Division 0.004mm
  • Stage
    Double Layer Mechanical Stage
  • Condenser
    Abbe N.A.1.2 With Iris, Rack & Pinion Adjustment
  • Illumination
    S-LED Illumination, Brightness Adjustable
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A11.1002
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope

Get Price Contact Now
  • Compact Design Student Biological Microscope
  • Monocular, Binocular Head Available, With WF10x/18mm Eyepiece
  • Quadruple Nosepiece With Achromatic Objective 4x10x40x100x
  • Attachable Mechanical Stage, Double Layer Mechanical Stage Optional
  • Coaxial Coarse & Fine Focuing, S-LED Illumination, Brightness Adjustable
A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 0

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 1

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 2

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 3

Binocular Head, Inclined 30° for A11.1002-B

Monocular Head, Inclined 45°for A11.1002-A/C


A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 4

Double Layer Mechanical Stage for A11.1002-B/C

Achromatic Objective 4x,10x,40x,100x


A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 5

Abbe N.A.1.2 With Iris

S-LED Illumination, Brightness Adjustable

A11.1002 Mechanical Stage LED Illumination Achromatic Binocular Biological Microscope 6
A11.1002 Biological Microscope A B C
Head Monocular Head, Inclined 45° ● 　 ●
Binocular Head, Inclined 30° 　 ● 　
Eyepiece Wide Field Eyepiece WF10x/18 ● ● ●
Objective Achromatic Objective 4x ● ● ●
Achromatic Objective 10x ● ● ●
Achromatic Objective 40x ● ● ●
Achromatic Objective 100x ● ● ●
Nosepiece Quadruple Nosepiece ● ● ●
Focusing Coaxial Coarse & Fine Focusing, Fine Division 0.004mm, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.4mm Per Rotation, Moving Range 24mm ● ● ●
Stage Attachable Mechanical Stage, Size 110*120mm,Moving Range 60*30mm ● 　 　
Double Layer Mechanical Stage, Size 125*120mm,Moving Range 60*30mm 　 ● ●
Condenser Abbe NA1.2 With Iris, Spiral Up & Down ● 　 　
Abbe N.A.1.2 With Iris, Rack & Pinion Adjustment 　 ● ●
Illumination S-LED Illumination, Brightness Adjustable ● ● ●
Filter Blue Filter ● ● ●
Green Filter ● ● ●
Optional Accessories Item No.
Head Duel Viewing Head A53.1003-1
Eyepiece Wide Field Eyepiece P16x A51.1002-16
IIlumination Plan-concave Mirror A56.1001-1
