OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope

OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope

Products - Compound Optical Microscope
  • Highlight

    OPTO-EDU Biological Laboratory Microscope

    ,

    Achromatic LED Biological Laboratory Microscope

    ,

    Achromatic LED Trinocular Biological Laboratory Microscope

  • Head
    Siedentopf Head
  • Eyepiece
    Wide Field Eyepiece WF10x/ 18
  • Objective
    Achromatic Objective
  • Nosepiece
    Backward Quadruple Nosepiece
  • Working Stage
    Double Layers Mechanical Stage132x142mm/ 75x40mm
  • Focusing
    Coaxial Coarse & Fine Knob, Moving Range 24mm
  • Condenser
    Abbe Condenser N.A.1.25 With Iris Diaphram & Filter
  • Illumination
    LED 3W, Brightness Adjustable
  • Place of Origin
    China
  • Brand Name
    OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A12.1005
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope

  • OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope
  • OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope
  • OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope
  • OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope
Get Price Contact Now
OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 0

OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 1

OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 2

OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 3

Interpupillary Distance 180° Adjustable


OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 4

Achromatic Objective

Double Layers Mechanical Stage


OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 5

Abbe Condenser N.A.1.25

LED 3W, Brightness Adjustable


OPTO EDU A12.1005 Achromatic LED Trinocular Biological Laboratory Microscope 6

A12.1005 Biologcial Microscope A B
Head Siedentopf binocular head, inclined at 30°, interpupilary distance 48-75mm ● 　
Siedentopf trinocular head, inclined at 30°, interpupilary Distance 55-75mm 　 ●
Eyepiece Wide field eyepiece WF10x/ 18 ● ●
Objective Achromatic objective 4x ● ●
Achromatic objective 10x ● ●
Achromatic objective 40x ● ●
Achromatic objective 100x ● ●
Nosepiece Backward quadruple nosepiece ● ●
Stage Double layers mechanical stage132x142mm/ 75x40mm ● ●
Focusing Coaxial coarse & fine knob, moving range 24mm, fine division 0.004mm ● ●
Condenser Abbe condenser N.A.1.25 with Iris diaphram & filter ● ●
Illumination LED 3W, brightness adjustable ● ●
Optional Accessories Item No.
Eyepiece P16x/11 A51.1002-16
Phase Contrast Kit A5C.1009
Polarization Attachment A5P.1003
Illumination Halogen lamp 6V/ 20W, brightness adjustable A56.1003
Dark Field Condensor A5D.1005
