6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906

6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906

Products - Phase Contrast Microscope
  • High Light

    phase contrast light microscope

    ,

    phase contrast microscopes

  • Certification
    CE
  • Drawtube
    Binocular
  • Illumination
    6V20W Halogen Lamp
  • Theory
    Phase Contrast Microscope
  • Working Stage
    150*140mm
  • Filter
    Blue
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE,
  • Model Number
    A19.0906
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906

  • 6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906
  • 6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906
Get Price Contact Now

6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906





--Compact Design For Appearance And Structure, with Infinity Color Correct Optical System
--Ergonomic Design, Easy Operation, Outstanding Optical Performance, Clear and Bright Image
--Specially Developed for Phase Contrast Observation, High Contrast, High Resolution, Highlight the Cell Outline and Internal Structure
--High Precision Focusing Device and COnvernient Illumination Adjustment





A19.0906 Phase Contrast Microscope
Head
Binocular, 30° Inclined, 360° Rotatable, Interpupillary Range 54~75mm
Eyepiece

PL10x/18mm, Wide Field, High Eyepoint
Phase Contrast Set

Plan Phase Contrast Objective 10X/0.25
Plan Phase Contrast Objective 20X/0.50
Plan Phase Contrast Objective 40X/0.65
Plan Phase Contrast Objective 100X/1.25
Centering Telescope Eyepiece, Dia. 23.2mm
Phase Contrast Slide, for 10x, 40x Objective
Phase Contrast Slide, for 20x,100x Objective
Nosepiece Reversed Quadruple
Focusing Coaxial Coarse & Fine Focusing, Low Position Design, Coarse Focusing Range 28mm, Fine Focusing Precision 0.002mm, With Tension Adjustment and Up Limit
Working Stage Double Layer Mechanical Stage, 150*140mm, Moving Range 76*50mm, Precision 0.1mm, Double Slide Holer, Low Position Coaxial Regulating Handles
Condenser Abbe N.A.1.25 Condenser, With Iris Diaphragm, With Filter Holder
Filter Blue, Dia. 45mm
Light Source Critical Illumination, 6V20W Halogen Lamp, Center Pre-adjusted
Power 90~240V Wide Range Power Supply



6V20W Illumination Phase Contrast Microscopy Infinity System with Plan Objective A19.0906 0
