Infinity Plan Phase Contrast Microscope with Kohler 3W LED Illumination A19.0907
--Compact Design For Appearance And Structure, with Infinity Color Correct Optical System
--Ergonomic Design, Easy Operation, Outstanding Optical Performance, Clear and Bright Image
--Specially Developed for Phase Contrast Observation, High Contrast, High Resolution, Highlight the Cell Outline and Internal Structure
--High Precision Focusing Device and COnvernient Illumination Adjustment
|
A19.0907 Phase Contrast Microscope
|
||
|---|---|---|
| Head | Binocular, 30° Inclined, Interpupillary Distance 54-75mm | |
|
Eyepiece
|
PL10x/18mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree
|
|
| Phase Contrast Set |
Infinity Plan Phase Contrast Objective 10X/0.25 |
|
| Infinity Plan Phase Contrast Objective 20X/0.50 | ||
| Infinity Plan Phase Contrast Objective 40X/0.65 | ||
| Infinity Plan Phase Contrast Objective 100X/1.25 | ||
| Centering telescope | ||
| Phase Contrast Slide, for 10x, 40x Infinity Objective | ||
| Phase Contrast Slide, for 20x,100x Infinity Objective | ||
| Nosepiece | Backward Quadruple | |
| Focusing | Low Position Coaxial Coarse & Fine Focusing Knob, with Safty Limitation and Tension Adjustment Ring. Coarse Range 25mm, Fine Precision 0.002mm | |
| Working Stage | Double Layer Mechanical Stage 140*132mm, Moving Range 76*50mm, Precision 0.1mm | |
| Condenser | Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed | |
| Light Source | 3W LED, Intensity Adjustable, Center Fixed | |
| Power |
90~240V Wide Range Power Supply |
|
