Sliding / Seidentopf Binocular Biological Microscope with 6V 20W Halogen Lamp A11.0303
A11.0303 Microscope,
--Achromatic Objectives
--WF10x/18mm Wide Field Eyepiece
--Monocular, Binocular, Trinocular Head Optional
--Mechanical stage
Specification |
A11.0303 Biological Microscope
|
M |
D
|
B
|
T
|
---|---|---|---|---|---|
Head
|
Monocular head, inclined 45°, rotatable 360° |
●
|
|
|
|
Dual Viewing head, inclined 45°, rotatable 360° |
|
●
|
|
|
|
Binocular head,inclined 30°, interpupillary distance 55-75mm |
|
|
●
|
|
|
Trinocular head, inclined 30°, interpupillary distance 55-75mm
|
|
|
|
●
|
|
Eyepiece
|
WF10x/18mm |
||||
Nosepiece | Quadruple nosepiece | ||||
Objective | Achromatic Objective 4x/NA 0.1 | ||||
Achromatic Objective 10x/NA 0.25 | |||||
Achromatic Objective 40x(s)/NA 0.65 | |||||
Achromatic Objective 100x(s,oil)/NA.1.25 | |||||
Stage | Mechanical stage size 140x120mm, moving range 70x40mm, minimum vernier division 0.1mm | ||||
Focusing | Coaxial coarse & fine focusing knob, coarse focusing range 20mm, fine focusing division 0.002mm | ||||
Condenser | N.A.1.25 Abbe condenser, up/down range 15mm | ||||
Filter | Blue filter | ||||
Light Source | 6V 20W Halogen lamp, brightness adjustable | ||||
Optional Accessory
|
Item No.
|
||||
Head | Seidentopf binocular head,inclined 30°, interpupillary distance 55-75mm |
A53.0304-01
|
|||
Seidentopf Triinocular head,inclined 30°, interpupillary distance 55-75mm | A53.0304-02 | ||||
Eyepiece | WF16x |
A51.0301-16
|
|||
WF20x | A51.0301-20 | ||||
Objective | Achromatic 20x (S) | A52.0301-20 | |||
Achromatic 60x (S) | A52.0301-60 | ||||
Plan 4x | A52.0303-04 | ||||
Plan 10x | A52.0303-10 | ||||
Plan 20x(S) | A52.0303-20 | ||||
Plan 40x(S) | A52.0303-40 | ||||
Plan 60x(S) | A52.0303-60 | ||||
Plan 100x(O,S) | A52.0303-100 | ||||
Condenser | Dark field condenser, dry |
A57.0310-01
|
|||
Dark field condenser, immersion | A57.0310-02 |
