Inverted Metallurgical Optical Microscope Trinocular Compound Optical Microscope
-
Highlight
reflected light microscope
,halogen lamp microscope
-
Optical SystemInfinity Color Corrected Optical System
-
HeadCompensation Trinocular Head
-
Place of OriginChina
-
Brand NameCNOEC, OPTO-EDU
-
CertificationCE, Rohs
-
Model NumberA13.0909
-
Document
-
Minimum Order Quantity1 pc
-
PriceFOB $1~1000, Depend on Order Quantity
-
Packaging DetailsCarton Packing, For Export Transportation
-
Delivery Time5~20 Days
-
Payment TermsT/T, West Union, Paypal
-
Supply Ability5000 pcs/ Month
Inverted Metallurgical Optical Microscope Trinocular Compound Optical Microscope
Inverted Metallurgical Optical Microscope , Compound Optical Microscope
A13.0909 Metallurgical Microscope, newly developed in 2013.
--Infinity Color Corrected Optical System With Newly Upgraded Koehler Illumination System, Presents Clear & Bright Micro-image Under Each Magnification.
--Fire-new Ergonomic Design, Steady System Structure, Easy Operation, Suitable For Various Working Environments.
--Newly Designed Integrative Y-Shape Body, All Metal Diecasted Under High Pressure. High stability, No Image Dithering Under High Magnification Observation, Ensures The Test Precision Of Multi-channel Fluorsecnce Diagnosis.
--LWD Infinity Plan Achromatic Metallurgical Objectives 5x, 10x, 20x, 50x, 100x
--Reflect & Transmit Light Source 5W LED Warm Color With Full Range Filters
| A13.0909 Metallurgical Microscope Specification | R | RT | |
| Optical System | Infinity Color Corrected Optical System | ||
| Head | Compensation Trinocular Head, 30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Splitting Ratio R:T=100:0/0:100, Diopter +/-5 Adjustable. | ||
| Eyepiece | High Eye-point Wide Field Plan Eyepiece PL10x22mm | ||
| Objective | LWD Infinity Plan Achromatic Metallurgical Objectives | ||
| 5x LMPL5x/0.15, WD10.8mm | |||
| 10x LMPL10x/0.3, WD12.2mm | |||
| 20x LMPL20x/0.45, WD12.2mm | |||
| 50x LMPL50x/0.55, WD7.9mm | |||
| Nosepiece | 5 Holes Revolving Nosepiece, Backward | ||
| Focusing | Coaxial Focus System With Upper Limited And Tension Adjustment, Coarse Range 25mm, Fine Precision 0.002mm | ||
| Working Stage | For Reflect Light | • | |
| Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment, With Metal Plate, Up/Down Range Accept 78mm High Sample | |||
| For Transmit & Reflect Light | • | ||
| Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment, With Glass Plate, Up/Down Range Accept 28mm High Sample | |||
| Light Source | Reflect Light | • | • |
| Lamp House With Single 5W LED, Warm Color, Koehler Illuminator With Oblique Light Device, Center Adjustable Field And Aperture Diaphragm, Interference Filter Blue <480nm, Green 520~570nm, Red 630~750nm, White Balance | |||
| Transmit Light | • | ||
| Lamp House With Single 5W LED, Warm Color, Filter: Yellow, Neutral, IF550, LBD, Condenser N.A. 0.9/0.25 Swing-out Achromatic Condenser For Transmit Light, With Center Adjustable Aperture Iris Diaphragm | |||
| Power | Wide Range Voltage 100~240V AC 50/60Hz | ||
| Optional Accessories | |||
| Eyepiece | High Eye-point PL10x/22mm with Micrometer, Diopter Adjustable | A51.0905-1022R | |
| High Eye-point PL15x/16mm | A51.0903-1516 | ||
| Objective | LWD Infinity Plan Ac hromatic Metallurgical Objectives 100X LMPL100X/0.8, WD2.1mm | A5M.0954-100 | |
| CCD Adapter | 1x C-Mount, Focus Adjustable | A55.0926-10 | |
| 0.50x, For 1/2” C-Mount, Focus Adjustable | A55.0926-50 | ||
| 0.67x, For 2/3” C-Mount, Focus Adjustable | A55.0926-67 | ||
