Laboratory 40X - 1600X Binocular Microscope With CE A12.0901
40-1600x Binocular Laboratory Microscope A12.0901
--195mm Achromatic Objectives, Mechanical Tube Length 160mm
--WF10x/18mm Large Field, Wide Angle Eyepiece, All Can Be Mounted With Reticle or Pointer
--Monocular, Binocular, Trinocular Head Optional
--Low Position Coaxial Coarse & Fine Focus System
--Double Layer Mechinal Stage
A12.0901 Laboratory Biological Microscope |
A |
B |
C |
D |
E |
|
Magnification |
40x~1600x |
|||||
Head |
Monocular Head, 45° Inclined |
o |
|
|
|
|
Sliding Binocular Head, 45° Inclined |
|
o |
|
|
|
|
Sliding Trinocular Head, 45° Inclined |
|
|
o |
|
|
|
Compensation Free Binocular Head, 30° Inclined |
|
|
|
o |
|
|
Compensation Free Trinocular Head, 30° Inclined |
|
|
|
|
o |
|
Eyepiece |
Wide Field WF10x/18mm, High Eyepoint |
o |
o |
o |
o |
o |
Wide Field WF15x/13mm, High Eyepoint |
o |
o |
|
|
|
|
Wide Field WF16x/14mm, High Eyepoint |
|
|
o |
o |
o |
|
Nosepiece |
Quadruple Nosepiece |
|||||
Objective |
Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil) |
o |
o |
|
|
|
Plan Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil) |
|
|
o |
o |
o |
|
Stage |
Double Layer Mechanical Stage, 132*140mm, Mvoing Range 50*76mm, Precision 0.1mm |
|||||
Focusing |
Low Position Coaxial Coarse & Fine Focusing. Fine Focusing Scale 0.002mm, With Tension Adjustment, With Up Limit |
|||||
Condenser |
N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder |
|||||
Filter |
Blue, Yellow, Green |
|||||
Light Source |
Built-in Illumination 230V/20W Tungsten Bulb |
|||||
A12.0901 Laboratory Biological Microscope Optional Accessories |
||||||
Eyepiece |
WF10x/18mm with Reticle |
A51.0905-1018R |
||||
WF10x/18mm with Pointer |
A51.0906-1018 |
|||||
WF20x/10mm |
A51.0902-2010 |
|||||
Objective |
Achromatic 60xs/0.85 |
A52.0901-60 |
||||
Plan Achromatic 25xs/0.40 |
A52.0903-25 |
|||||
Adapter |
1.0x C-Mount |
A55.0922-10 |
||||
0.5x C-Mount, For 1/2" CCD, Focus Adjustable |
A55.0922-05 |
|||||
0.35x C-Mount, For 1/3" CCD, Focus Adjustable |
A55.0922-35 |
