Industry Metallurgical Optical Microscope

Industry Metallurgical Optical Microscope

  • High Light

    reflected light microscope


    bright field microscope

  • Application
    Research, Learning, Metallurgical
  • Certification
    CE, Rohs
  • Drawtube
  • Illumination
    Halogen Lamp
  • Magnification
    50X - 500X
  • Theory
    Metallurgical Optical Microscope
  • Place of Origin
  • Brand Name
  • Certification
    CE, Rohs
  • Model Number
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Industry Metallurgical Optical Microscope


Industry Trinocular Metallurgical Optical Microscope A13.0216




A13.0216 Metallurigical Microscope
Trinocular head, inclination of 22.5 °,diopter adjustment 5, interpupillary 53mm-75mm
Wide field WF10X(field number:Φ22mm)
Infinity Plan Achromatic Objective
PL L5X/0.12  (Work distance):26.1 mm (Bright field)
PL L10X/0.25 (Work distance):20.2 mm ( Bright field)
PL L20X/0.40 (Work distance):8.8. mm (Bright field)
PL L50X/0.70 (Work distance):3.68 mm (Bright field)
PL L5X/0.12 (Work distance):9.7 mm (Bright /Dark field)
PL L10X/0.25 (Work distance):9.3 mm (Bright /Dark field)
PL L20X/0.40 (Work distance):7.2 mm (Bright /Dark field)
PL L50X/0.70 (Work distance):2.5 mm (Bright /Ddark field)
PL L5X/0.10 (Work distance):18.2 mm (DIC)
PL L10X/0.25 (Work distance):20.2 mm (DIC)
PL L20X/0.35 (Work distance):6.0mm (DIC)
PL L50X/0.70 (Work distance):2.5 mm (DIC)
12V50W halogen and brightness adjustable
For LMPlan 5x/10x/20x objective DIC flashboard
Focus System
Coaxial coarse/fine focus system, with coarse focus knob tension adjustable device, minimum division of fine focusing: 2μm. Max. hight of sample: 100mm. Range: 35mm
Quintuple nosepiece
Filter Gross filter, yellow, green, blue filters
Base overall size:300mmX250mm
Mechanical stage overall size:160mmX140mm, moving range:30mmx35mm


Industry Metallurgical Optical Microscope 0Industry Metallurgical Optical Microscope 1
