Optional Accessories
|
Item No. |
|
Eyepiece |
Wide field WF16x/11mm |
A51.0203-16A |
|
Divding 10x, 0.1mm/Div |
A51.0205-10 |
|
Objective
|
Plan achromatic 4x/0.10 |
A52.0203-4 |
|
Plan achromatic 5x/0.12 |
A52.0203-5 |
|
Plan achromatic 10x/0.25 |
A52.0203-10 |
|
Plan achromatic 20x/0.40 |
A52.0203-20 |
|
Plan achromatic 40x/0.65(Spring) |
A52.0203-40 |
|
Plan achromatic 60x/0.85(Spring) |
A52.0203-60 |
|
Plan achromatic 100x/1.25(Spring, Oil) |
A52.0203-100 |
|
Head
|
Binocular, inclination of 45° |
A53.0206 |
|
Trinocular, inclination of 45° |
A53.0209 |
|
Trinocular, inclination of 30° |
A53.0207-5 |
|
Dual viewing, inclination of 30° |
A53.0203-2 |
|
Nosepiece
|
Quintuple (Backward ball bearing inner locating) |
A54.0203-1 |
|
Filter |
Green filter |
A54.0209-2 |
|
Yellow filter
|
A54.0209-3 |
|
Light Source
|
LED collector, bright and white light |
A56.0204-9 |
|
Condenser |
Dark field, dry |
A5D.0201 |
|
Dark field, immersion
|
A5D.0202 |
|
Phase Contrast Attachment |
Centering telescope |
A5C.0204-1 |
|
Objective, Phase contrast plan 10x/0.25 PHP
|
A5C.0211-10 |
|
Objective, Phase contrast plan 20x/0.40 PHP(Spring) |
A5C.0211-20 |
|
Objective, Phase contrast plan 40x/0.65 PHP(Spring) |
A5C.0211-40 |
|
Objective, Phase contrast plan 100x/1.25 PHP (Spring,oil) |
A5C.0211-100 |
|
PH-I Turnplate phase contrast condenser |
A5C.0202-1 |
|
PH-II Turnplate phase contrast condenser |
A5C.0202-4 |
|
Flashboard phase contrast set |
A5C.0202-2 |
|
Pull board phase contrast set
|
A5C.0202-3 |
|
Infinity Optical System |
Binocular head inclination of 30° |
A53.0205-2 |
|
Trinocular head inclination of 30°
|
A53.0208-2 |
|
Centering telescope |
A5C.0204-2 |
|
Objective, infinity plan achromatic 4x/0.10 |
A52.0206-4 |
|
Objective, infinity plan achromatic 10x/0.25 |
A52.0206-10 |
|
Objective, infinity plan achromatic 20x/0.25 |
A52.0206-20 |
|
Objective, infinity plan achromatic 40x/0.65(Spring) |
A52.0206-40 |
|
Objective, infinity plan achromatic 100x/1.25(Spring, oil) |
A52.0206-100 |
|
Objective, infinity phase contrast plan 10x/0.25 PHP |
5C.0216-10 |
|
Objective, infinity phase contrast plan 20x/0.40 PHP (Spring) |
5C.0216-20 |
|
Objective, infinity phase contrast plan 40x/0.65 PHP (Spring) |
5C.0216-40 |
|
Objective, infinity phase contrast plan 100x/1.25 PHP (Spring, oil)
|
5C.0216-100 |
|
CCD adapter |
0.4x |
A55.0202-1 |
|
0.5x |
A55.0202-4 |
|
1x |
A55.0202-2 |
|
0.5x with dividing 0.1mm/Div |
A55.0202-3 |
|
Digital Camera Adapter |
Canon ditigal camera adapter (A610, A620, A630, A640)
|
A55.0204-01 |
|
Photo Adapter |
2.5x/4x change over photograph attachment with 10x viewing eypiece
|
A55.0201-1 |
|
4x focusing photograph attachment |
A55.0201-2 |
|
MD adapter |
A55.0201-3 |
|
PK adapter
|
A55.0201-4 |
|
Adapter |
Input: 230V<50/60HZ Output: 9V 500mA |
A56.0205-1 |
|
Input: 110V<50/60HZ Output: 9V 500mA |
A56.0205-2 |
|
Polarizing Attachment |
Polarizer 360° rotatable |
A5P.0201 |
|
Analyzer |
