Laboratory 1000X Compound Optical Microscope , Rohs CE A12.1007
Specifications:
|
A12.1007 Biologcial Microscope
|
|
Head
|
Siedentopf binocular head, inclined at 30°,360° Rotatable |
|
Eyepiece
|
Wide field eyepiece WF10x/ 18 |
|
Objective
|
Achromatic Objective 4x |
|
Achromatic Objective 10x |
|
Achromatic Objective 40x |
|
Achromatic Objective 100x |
|
Nosepiece
|
Backward quadruple nosepiece |
|
Stage
|
Double Layers Mechanical Stage 140×140mm/ 75×50mm |
|
Focusing
|
Coaxial coarse & fine adjustment system, range 28mm, fine division 0.002mm |
|
Condenser
|
Abbe condenser N.A.1.25 with Iris diaphram & filter,rack & pinion adjustment |
|
Filter
|
Green Filter |
|
Illumination
|
|
|
|
Optional Accessories
|
Item No.
|
|
Head
|
Monocular head, inclined at 30°,360° Rotatable |
A53.1002-3
|
|
Seidentopf trinocular head, inclined at 30°,360° Rotatable |
A53.1004-2
|
|
Eyepiece
|
Wide Field Eyepiece WF16x/ 11 |
A51.1002-16
|
|
Objective
|
Achromatic objective 20x |
A52.1001-20
|
|
Achromatic objective 60x |
A52.1001-60
|
|
Plan Achromatic Objective 4x |
A52.1006-4
|
|
Plan Achromatic Objective 10x |
A52.1006-10
|
|
Plan Achromatic Objective 20x |
A52.1006-20
|
|
Plan Achromatic Objective 40x |
A52.1006-40
|
|
Plan Achromatic Objective 60x |
A52.1006-60
|
|
Plan Achromatic Objective 100x |
A52.1006-100
|
|
Nosepiece
|
Backward quintuple nosepiece |
A54.1001-5M
|
|
Illumination
|
Halogen lamp 6V/ 20W, brightness adjustable |
A56.1003-6V20 |
|
Kohler illumination |
A56.1005-3
|
|
Video Attachment
|
1X CMOUNT |
A55.1002-10 |
|
0.5X CMOUNT |
A55.1002-05
|
|
Epi-fluorescent Attachment
|
XY-2 EPI-fluorescent Attachment |
A5F.1001 |
|
FL-LED EPI-fluorescent Attachment |
|
|
Phase Contrast Attachment
|
Simple phase contrast set |
A5C.1001
|
|
Sliding phase contrast set |
A5C.1002-C3
|
|
Turret phase contrast set |
A5C.1003-B1
|
|
Polarization Set
|
Simple polarization set |
A5P.1001
|
|
Dark Field Condensor
|
Dark field condenser (Dry) N.A. 0.9 |
A5D.1010-BD
|
|
Dark field condenser (Oil) N.A. 1.25-1.36 |
A5D.1010-BI
|
|
