Laboratory Binocular Compound Optical Microscope Phase Contrast A12.0205
New Product in 2011!
A12.0205 biological microscopes is equipped with infinity plan achromatic objectives and wide field eyepieces. It have beautiful sculpt and provide clear image, wide field, convenience operation. It can be used for biology medicine agriculture and industry area widely. It is the ideal instrument in medical treatment, teaching demonstration and scientific research.
Specifications:
|
|
A12.0205
|
|
Head |
Trinocular,inclination of 30° |
|
Eyepiece
|
WF10X(Φ22mm)
|
|
Infinity Plan Achromatic Objective
|
PL 4X/0.10 (Work distance):19.8 mm
|
|
PL 10X/0.25 (Work distance):5.0 mm
|
|
PL 40X/0.65 (Spring) (Work distance):0.66 mm |
|
PL 100X/1.25 (Spring, oil) (Work distance): 0.36mm
|
|
Focus System
|
Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um
With tensional adjustable and up stop, |
|
Nosepiece
|
Quadruple (backward ball bearing inner locating)
|
|
Stage
|
Double layer mechanical, size 193x155mm, moving range 75x50mm
|
|
Transmitted Illumination
System
|
Abbe condenser NA.1.25 Rack & pinion adjustable
|
|
Blue filter and Ground glass |
|
LED, High Brightness, Light Adjustable |
|
|
Optional Accessories
|
Item No. |
|
Eyepiece |
Dividing eyepiece(field number:|μ22mm) , 0.1mm/Div |
A51.0205-G10B
|
|
Infinity Plan Achromatic Objective |
PL 20X/0.40 (Work distance:8.8 mm |
A52.0206-20
|
|
PL 60X/0.85 (Work distance):0.25mm |
A52.0206-60
|
|
Filter |
Green filter |
A56.0209-02 |
|
Yellow filter
|
A56.0209-03 |
|
Phase Contrast Unit |
Centering telescope |
A5C.0212-1 |
|
Objective, Phase contrast plan 10x/0.25 PHP
|
A5C.0230-P10 |
|
Objective, Phase contrast plan 20x/0.40 PHP(Spring) |
A5C.0230-P20 |
|
Objective, Phase contrast plan 40x/0.65 PHP(Spring) |
A5C.0230-P40 |
|
Objective, Phase contrast plan 100x/1.25 PHP (Spring,oil) |
A5C.0230-P100 |
|
CCD adapter |
0.4x |
A55.0202-01 |
|
0.5x |
A55.0202-04 |
|
1x |
A55.0202-02 |
|
0.5x with dividing 0.1mm/Div |
A55.0202-03 |
|
Digital Camera Adapter |
For Canon EF ditigal SLR camera adapter
|
A55.0204-02 |
|
Polarizing Attachment |
Polarizer 360° rotatable |
A5P.0210-1 |
|
Analyzer |
A5P.0211-1 |
|
