Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604

Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604

  • High Light

    reflected light microscope

    ,

    halogen lamp microscope

  • Application
    Research, Learning, Metallurgical
  • Certification
    CE, Rohs
  • Drawtube
    Trinocular
  • Illumination
    Halogen Lamp
  • Magnification
    50x - 1000x
  • Theory
    Metallurgical Optical Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A13.2604
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604



Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604



Description:

A13.2604 Metallurgical Microscope

--Infinity optical system for metallurgical observing
--Stress Free Long working distance objective
--Reflecting & transmitting light source available
--Polarizing Set Included
--Kohler illumination collector with field diaphragm


Specifications:


Specification
A13.2604 Metallurgical Microscope
A
B
HeadTinocular, inclinded 30°, interpupillary distance 50-75mm
EyepieceWF10X/18mm
WF10X -18 mm (Reticule 0.1mm)
ObjectiveInfinity Plan Metallurgical Objective
(no cover glass)
5x/0.1, WD=6.73mm
10x/0.25, WD=4.19mm
20x/0.4(s), WD=2.14mm
100x/1/25(oil)(s), WD=0.12mm
LWD Infinity Plan Metallurgical Objective (no cover glass)40x/0.65(s), WD=3.90mm
NosepieceQuintuple Backward
StageMechnical Stage for Reflection Illumination, Size: 190×140mm, Travel Range: 78×55mm, Stage Fast Lowing Unit, Stage Up-Down moving range 50mm (Max.)

Mechnical Stage for Transmit llumination, Size: 190×140mm, Travel Range: 78×55mm, Coaxial Coarse and Fine Focusing Knobs
PlateStage Plate: Place The Sample on The Plate
Clip
PolarizingPolarizing /Analyzer Slide
CondenserAbbe N.A. 1.25, with iris diaphragm
FocusingCoaxial coarse and fine focusing knob, coarse focusing range 25mm, fine focusing scale 2um, with tension adjustment
Light SourceReflecting light, 12V 50W halogen lamp
Transmiting light, 6V 20W halogen lamp, Center Adjustable Kohler Collector
CollectorKohler illumination collector with field diaphragm
FilterBlue
Packing1pc/carton, size 75x36x45cm, G/N weight 16/15Kgs
Optional Accessories
Item No.
EyepieceWF 5x/20mmA51.2602-05
WF12.5x/14mmA51.2602-125
WF16x/13mmA51.2602-1613
ObjectiveInfinity Plan Metallurgical Objective
(no cover glass)
40x/0.65(s),WD=0.45mmA5M.2632-40
LWD Infinity Plan Metallurgical Objective
(no cover glass)
20x/0.4(s),WD=8.35mmA5M.2633-20
50x/0.7(s),WD=1.95mmA5M.2633-50
80x/0.8(s),WD=0.85mmA5M.2633-80
StageGlass Plate for Transmit LightA54.2605
Stage Micrometer 0.01mmA58.2601
AdapterC-Mout 0.5xA55.2601-MT05
C-Mout 1.0xA55.2601-MT10
