Binocular Head Compound Metallurgical Optical Microscope A13.0209

Binocular Head Compound Metallurgical Optical Microscope A13.0209

Products - Metallurgical Optical Microscope
  • Highlight

    bright field microscope

    ,

    halogen lamp microscope

  • Application
    Research, Metallurgical
  • Certification
    CE, Rohs
  • Drawtube
    Binocular
  • Illumination
    Halogen Lamp, LED
  • Magnification
    50X - 500X
  • Theory
    Metallurgical Optical Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A13.0209
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Binocular Head Compound Metallurgical Optical Microscope A13.0209

  • Binocular Head Compound Metallurgical Optical Microscope A13.0209
  • Binocular Head Compound Metallurgical Optical Microscope A13.0209
Get Price Contact Now


Binocular Compound Metallurgical Optical Microscope A13.0209


Description:

A13.0209 metallurgical microscope is used for identification and analysis of the structures in different metals and alloys, it is the important instrument for researching metallography in metal physics.
--Plan achromatic objectives with long working distance (no cover glass)
--Coaxial coarse/fine focusing system with tension adjustable and up stop
--6V 20W halogen lamp with brightness control
--Trinocular head can switch between normal observation and polarizing observation


Specifications:


Specification
A13.0209-A
A13.0209-B
Eyepiece
WF10X(Φ18mm)
Objective
Plan long working distance (no cover glass) PL5x/0.12
Plan long working distance (no cover glass) PLL10x/0.25
Plan long working distance (no cover glass) PLL20x/0.40
Plan long working distance (no cover glass) PLL50x/0.7
Head
Trinocular, inclination of 30°, analyzer with field diaphragm to switch
Vertical illumination Unit
6V 20W halogen lamp with brightness control
Vertical illumination with field diaphragm, aperture diaphragm and polaizer, (YBG) filter and ground glass
Transmited Illumination Unit Abbe condenser N.A.=1.25, Rack & pinion adjustable
Blue filter and ground glass
Collector for illumination with halogen lamp (With filed diaphragm)
6V 20W, halogen lamp, adjustable brightness
Focus System
Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2um
Nosepiece
Quadruple back ball bearing inner locating
Stage
Double layer mechanical, size 210x140mm, moving range 75x50mm
Optional Accessories
Item No.
EyepieceWide field WF16x/11mmA51.0203-16A
Divding 10x, 0.1mm/DivA51.025-G10
Objective

Plan long working distance (no cover glass) PLL40x/0.60A5M.0212-40
Plan long working distance (no cover glass) PLL60x/0.75(Spring)A5M.0212-60
Plan long working distance (no cover glass) PLL80x/0.80A5M.0212-80
Plan long working distance (no cover glass) PLL10x/0.85(Spring)A5M.0212-100A
Plan achromatic (no cover glass) PL100x/1.25A5M.0212-100
NosepieceQuintuple backward ball bearing inner locatingA54.0203-2
CCD Adapter0.4x
A55.0202-1
0.5x
A55.0202-4
1x
A55.0202-2
0.5x with dividing 0.1mm/Div
A55.0202-3
Photo Adapter
2.5x/4x change over photograph attachment with 10x viewing eypiece
A55.0201-1
4x focusing photograph attachmentA55.0201-2
MD adapterA55.0201-3
PK adapter
A55.0201-4
DC Adapter
Digital Camera Adapter for CANON(A610,A620,A630,A640)
A55.02024-01



Binocular Head Compound Metallurgical Optical Microscope A13.0209 0Binocular Head Compound Metallurgical Optical Microscope A13.0209 1
