A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research

China A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research supplier
A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research supplier A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research supplier A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research supplier A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research supplier

Large Image :  A13.0202 Trinocular Handheld Digital Microscope 50X - 600X Magnification Binocular For Research

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A13.0202

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Application: Research|Metallurgical Certification: CE|Rohs
Drawtube: Binocular Illumination: Halogen Lamp
Magnification: 50X - 600X Theory: Metallurgical Optical Microscope



Research Binocular Metallurgical Optical Microscope 50X - 600X A13.0202



Description:



This metallurgical microscope is used for identification and analysis of the structures in different metals and alloys, it is the important instrument for researching metallography in metal physics.

--Plan achromatic objectives with long working distance (no cover glass)
--Coaxial coarse/fine focusing system with tension adjustable and up stop
--6V 20W halogen lamp with brightness control
--Trinocular head can switch between normal observation and polarizing observation





Specifications:



Specification
A13.0202-A
A13.0202-B
Eyepiece
WF10X(Φ18mm)
Objective
Plan long working distance (no cover glass) PL5x/0.12
Plan long working distance (no cover glass) PL5x/0.12
Plan long working distance (no cover glass) PLL10x/0.25
Plan long working distance (no cover glass) PLL10x/0.25
  Plan long working distance (no cover glass) PLL20x/0.40
Plan long working distance (no cover glass) PLL40x/0.60
Plan long working distance (no cover glass) PLL40x/0.60
Plan long working distance (no cover glass) PL 60x/0.75 (Springl)
Plan long working distance (no cover glass) PL 60x/0.75 (Springl)
Head
Trinocular, inclination of 30°, analyzer with field diaphragm to switch
Vertical illumination
6V 20W halogen lamp with brightness control
Vertical illumination with field diaphragm, aperture diaphragm and polaizer, (YBG) filter and frosted filter
Focus System
Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2um
Nosepiece
Quadruple back ball bearing inner locating
Quintuple back ball bearing inner locating
Stage
Double layer mechanical, size 185x140mm, moving range 75x40mm
Optional Accessories
Item No.
Eyepiece Wide field WF16x/11mm A51.0203-16A
Divding 10x, 0.1mm/Div A51.0205-10
Objective
Plan long working distance (no cover glass) PLL50x/0.70 A5M.0212-50
Plan long working distance (no cover glass) PLL80x/0.80 A5M.0212-80
Plan long working distance (no cover glass) PLL100x/0.85(Spring) A5M.0212-100
Plan achromatic (no cover glass) PL100x/1.25 A5M.0234-100
CCD adapter 0.4x A55.0202-1
0.5x A55.0202-4
1x A55.0202-2
0.5x with dividing 0.1mm/Div A55.0202-3
Photo Adapter
2.5x/4x change over photograph attachment with 10x viewing eypiece
A55.0201-1
4x Focusing photograph attachment A55.0201-2
MD adapter A55.0201-3
PK adapter
A55.0201-4
DC Adapter
Canon ditigal camera adapter (A610, A620, A630, A640)
A55.0204-11
