Multifunction Compound Optical Microscope Biological Monocular 1000x Microscope

China Multifunction Compound Optical Microscope Biological Monocular 1000x Microscope supplier

Large Image :  Multifunction Compound Optical Microscope Biological Monocular 1000x Microscope

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A12.6603

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Type: Biological Microscope Optical System: Infinity Correct
Light Source: 3W LED Magnification: 1000x
Application: School Head: Binocular

Infinity E - plan Aspheric Illumination Compound Optical Microscope A12.6603



A12.6603 Laboratory Biological Microcope, Brand New Developed in 2014, is the best choice for your lab and school!

Perfect Optical System
Perfect Appearance Design
Perfect Ergonomics Design

Multifunction Compound Optical Microscope Biological Monocular 1000x Microscope
●Infinity Correct Optical System Supply High Resolution And Perfect Definition
●Aspheric 3W LED Light Source
●Drop-Style Integrated Appearance Design, Looks Elegant
●High Rigidity Body Struction Design Supply High Steady
●Low Position Operation For Convenient Using
● New Cable Holder For Easy Keeping Cable
● Holding Hole On Back For Easy Carrying And Watching



Items A12.6603 Biological Microscope Specification B T B2 T2 B3 T3 B4 T4 Cata. No.
Head Seidentopf Binocular Head, Inclined 30°,Rotatable 360°, Interpupilary Distance: 48-75mm         A53.2602-B
Seidentopf Trinocular Head, Inclined 30°,Rotatable 360°, Interpupilary Distance: 48-75mm, Light Split Fixed P20:E80 A53.2602-T
Digital Head, 5.0M 1/2" CMOS USB2.0 Digital Camera Built-in, Light Split Fixed P20/E80 A53.2602-5.0M
Digital Head, 5.0M 1/2" CMOS USB2.0 Digital Camera Built-in, Light Split Fixed P20/E80, With Holder For Pad A53.2602-5.0MH
Eyepiece WF10x/18mm         ●● ●● ●● ●● A51.2602-1018
WF10X/20mm (High Eyepoint) ●● ●● ●● ●●         A51.2602-1020
WF16x/13mm A51.2602-1613
WF10x/18mm With Pointer A51.2604-1018
WF10x/18mm With Micrometer 0.1mm*180 Div A51.2605-1018
WF10x/18mm With Micrometer 0.1mm*180 Div, Diopter Adjustable A51.2605-1018D
Nosepiece Quadruple, Backward A54.2610-N03
Infinity Eplan
Objective
EPLAN 4x/0.10,W.D.=12.1mm         A52.2605-4
EPLAN 10x/0.25,W.D.=4.14mm         A52.2605-10
EPLAN 40x/0.65(S),W.D.=0.58mm         A52.2605-40
EPLAN 100x/1.25(S, Oil),W.D.=0.19mm         A52.2605-100
Infinity Plan
Objective
PLAN 2.5x/0.07,W.D.=8.47mm         A52.2606-2.5
PLAN 4X/0.10.W.D.=12.1mm         A52.2606-4
PLAN 10X/0.25.W.D.=4.64mm         A52.2606-10
PLAN 20X/0.40(S).W.D.=2.41mm         A52.2606-20
PLAN 40X/0.66(S).W.D.=0.65mm         A52.2606-40
PLAN 60X/0.80(S).W.D.=0.33mm         A52.2606-60
PLAN 100X/1.25(S,Oil).W.D.=0.12mm         A52.2606-100
PLAN 100X/1.15(S,Water).W.D.=0.19mm         A52.2606-100W
Achromatic Objective 4x/0.1, W.D.=18.6mm         A52.2601-4
10x/0.25, W.D.=6.5mm         A52.2601-10
20x/0.40, W.D.=1.75mm         A52.2601-20
40x/0.6(S), W.D.=0.47mm         A52.2601-40
60x/0.80(S), W.D.=0.10mm         A52.2601-60
100x/1.25(S,O), W.D.=0.07mm         A52.2601-100
Plan
Objective
4x/0.1, W.D.=14.5mm         A52.2603-4
10x/0.25, W.D.=5.65mm         A52.2603-10
20x/0.40, W.D.=5.65mm         A52.2603-20
40x/0.6(S), W.D.=0.85mm         A52.2603-40
100x/1.25(S,O), W.D.=0.07mm         A52.2603-100
Working Stage Mechanical Stage Size 145×140mm, Travel Range 76×52mm, Scale 0.1mm, Double Slide Holder A54.2601-S04
Rackless (Integrated) Stage, Size 140×135mm,
Travel Range 75×35mm, Double Slide Holder
A54.2601-S12
Condenser Abbe Condenser N.A.1.25, Iris Diaphragm, Spiral Up/Down, With Filter Holder A56.2614-09
Focusing Coaxial Coarse & Fine Focusing, Coarse Focusing Travel Range: 25mm, Fine Focusing Scale 2µm/Division
Light Source 3W LED Illumination With Aspheric Collector, Wide Range Voltage: 100V~240V A56.2612-3W
Adapter 1.0x C-Mount Focus Adjustable         A55.2601-10
0.5x C-Mount Focus Adjustable         A55.2601-05
0.75x C-Mount Focus Adjustable         A55.2601-75
Digital Eyepiece Adapter, Dia.23.2mm/25mm         A55.2610
Dark Field Dark Field Ring, For 4x~40x Objective A5D.2611-B
Polarizing Analyzer + Polarizer Set A5P.2601-B3
Attachment Wire Winding Device A50.2602
Package Carton Size 345×260×455mm, 1 Unit/Ctn
Weight Gross Weight 7.0kgs, Net Weigth 5.5kgs
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
