Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source

China Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source supplier
Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source supplier Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source supplier Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source supplier Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source supplier

Large Image :  Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A13.2606-A

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Certificate: CE, Rohs Magnification: 50x100x200x500x
Drawtube: Trinocular Eyepiece: WF10x/22
Nosepiece: 4 Holes Objective: LWD Metallurgical Infinity Plan BF 5x10x20x50x
Working Stage: Three Layer Mechanical Stage Focusing: Coaxial Coarse & Fine
Light Source: 12V50W Halogen Power Supply: 100~240V

Opto-edu China Manufacturer Wholesales Price Advanced Optical Metallurgical Industrial Lab Used Microscope



Items A13.2606 Invered Metallurgical Microscope A13.2606 A13.2606-BD Cata. No.
Head Seidentopf Trinocular Head Inclined 30°, Interpupilary Distance 48~76mm, Light Split Switch E100:P0 / E20:P80 A53.2643
Eyepiece WF10x/22mm, Dia.30mm, High Eyepoint, Diopter Adjustable A51.2621-1022
WF10x/22mm, Dia.30mm, High Eyepoint, Diopter Adjustable,
With Micrometer X-0.1mm*180 Div / Y-Single Line
A51.2622-1022
WF15X/16mm, Dia.30mm, High Eyepoint, Diopter Adjustable A51.2621-1516
WF20X/12mm, Dia.30mm, High Eyepoint, Diopter Adjustable A51.2621-2012
Nosepiece Quintuple   A54.2610-N925
Quadruple(Specially For Bright&Dark Field objectives)   A54.2610-N924
Metallurgical LWD Infinity Plan BF
(Bright Field) Objectives
LPL 5x/0.13, W.D.=16.04mm   A5M.2633-5
LPL10x/0.25, W.D.=18.48mm   A5M.263310
LPL 20x/0.40, W.D.=8.35mm   A5M.2633-20
LPL 50x/0.70, W.D.=1.95mm   A5M.2633-50
LPL 80x/0.80, W.D.=0.85mm   A5M.2633-80
LPL 100x/0.90(Dry), W.D.=1.00mm   A5M.2633-100
Metallurgical LWD Infinity Plan BD
(Bright & Dark Field) Objectives
LPL 5x/0.13BD, W.D.=16.04mm   A5M.2634-5
LPL10x/0.25BD, W.D.=18.48mm   A5M.2634-10
LPL 20x/0.40BD, W.D.=8.35mm   A5M.2634-20
LPL 50x/0.70BD, W.D.=1.95mm   A5M.2634-50
Working Stage Stage Size 210×180mm, Moving Range 50×50mm, Scale 0.1mm, Round Plate Size Dia.110mm A54.2601-S11T
Round Plate With Oval Hole A54.2601-MD400
Focusing Coaxial Coarse & Fine Focusing, Coarse Focusing Travel Range: 10mm, Fine Focusing Div. 0.002mm, Fine Stroke Per Rotation 0.2mm
Polarizing Analyzer + Polarizer Set A5P.2602
Illumination Koehler Illumination Halogen 12V/50W, Input Voltage 100V~240V A56.2613-12V50W
Koehler Illumination 5W LED, Input Voltage 100V~240V A56.2651-5W
Power ECO, Auto Power Off System.
Power Off Automatically Upon User Leaving 10 Minutes,
Power On Automatically Upon User Approaching Detected,
This Function Can Be Shut Down Manually
A56.2660
Filter Blue, Dia.34mm A56.2616-34B
Green, Dia.34mm A56.2616-34G
Amber, Dia.34mm A56.2616-34A
Grey, Dia.34mm A56.2616-34N
Adapter SLR Digital Camera Adapter For Canon, 100% Light For Camera Portt A55.2622-BC
SLR Digital Camera Adapter For Nikon, 100% Light For Camera Port A55.2622-BN
C-Mount 0.5x, Focus Adjustable A55.2601-05
C-Mount 0.75x, Focus Adjustable A55.2601-75
C-Mount 1.0x, Focus Adjustable A55.2601-10
Digital Eyepiece Camera Adapter, Dia. 23.2mm/25mm A55.2610
Package Packing Size: 660mmx590mmx325mm
Weight Gross Weight: 17 kgs, Net Weight: 12.5 kgs
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.

Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source

Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source

Opto-Edu Digital Metallurgical Microscope Trinocular 12V 50W Halogen Light Source
