A43.1901 C Mount 1/3" Ccd Surgical Operating Microscope 2.9x - 21.7x Colposcope

A43.1901 C Mount 1/3" Ccd Surgical Operating Microscope 2.9x - 21.7x Colposcope

  • High Light

    colposcope surgical operating microscope

    ,

    21.7x surgical operating microscope

    ,

    2.9x surgical microscope

  • Total Magnification
    2.9x-21.7x
  • Magnification Changer
    5-step Magnification Change
  • Beamsplitter
    50: 50 Beamsplitter
  • TV Adapter
    C-mount 1/3" CCD Attachable
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE,
  • Model Number
    A43.1901
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

A43.1901 C Mount 1/3" Ccd Surgical Operating Microscope 2.9x - 21.7x Colposcope

Specifications
Model A43.1901-A A43.1901-B A43.1901-C A43.1901-D A43.1901-E
Observation angle 45° Tilted Binocular Observation Unit
Magnification of eyepiece 16X
Focal length of objective F=230mm & 280mm (Connecting screw: M58x0.75) F=280mm
(Connecting screw: M57x0.75)
Working distance 215mm & 260mm 265mm
Magnification changer 0.4X, 0.66X, 1X, 1.5X, 2.5X
5-step magnification change
No
Total magnification 2.9X-21.7X 11X
Linear field 11mm - 84mm 24mm
Beamsplitter 50:50 Beamsplitter No
Demonstrator Total magnification:2.1X-16.4X Optional
TV adapter C-mount 1/3" CCD attachable No
Photo adapter Optional No
Fine focusing distance 20mm 60mm 20mm
Balancing arm Counterweight adjustable No Counterweight adjustable
Illumination system Coaxial illumination with cold light source fiber-optic cable
12V 100W halogen lamp, brightness adjustable
Filter Green filter with frame, to be fitted on the objective when it is used
Fiber-optic cable 1300mm
Stand short column fitted on the round base with 5 jaws and a round counterweight ring Column height adjustable fitted on the round base with 3 jaws short column fitted on the round base with 5 jaws
