High Precision Monocular Light Microscope Mechnical Stage 40X-1600X Magnification

High Precision Monocular Light Microscope Mechnical Stage 40X-1600X Magnification

Products - Biological Microscope
  • Highlight

    binocular compound microscope

    ,

    wide field microscope

  • Magnification
    40X-1600X
  • Head
    Binocular Or Trinocular
  • Eyepiece
    WF 10X/18mm
  • Nosepiece
    Quadruple Revolving Nosepiece
  • Stage
    Mechnical Stage 150mmx135mm, Vernier Scale Travel Range 77mmx50mm With Graduation Of 0.1mm
  • Place of Origin
    China
  • Brand Name
    OPTO-EDU
  • Model Number
    A11.0106
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1
  • Price
    USD 672.5-433.9

High Precision Monocular Light Microscope Mechnical Stage 40X-1600X Magnification

  • High Precision Monocular Light Microscope Mechnical Stage 40X-1600X Magnification
Get Price Contact Now

1

A11.0106 Specificiation
A
B
C
D
Magnification
40X-1600X
●
●
●
●
Head
Sliding Binocular Head, 45°Inclined, 360°Rotatable, Interpupilary Distance 55-75mm
●
-
-
-
Seidentopf Binocular Head, 45°Inclined, 360°Rotatable, Interpupilary Distance 55-75mm
-
●
-
-
Sliding Trinocular Head, 45°Inclined, 360°Rotatable, Interpupilary Distance 55-75mm
-
-
●
-
Seidentopf Trinocular Head, 45°Inclined, 360°Rotatable, Interpupilary Distance 55-75mm
-
-
-
●
Eyepiece
WF10X/18mm
●
●
●
●
Objective
Achromatic 4X/0.10
●
●
-
-
Achromatic 10X/0.25
●
●
-
-
Achromatic 40X/0.65, Spring
●
●
-
-
Achromatic 100X/1.25, Spring, Oil
●
●
-
-
Semi-plan 4X/0.10
-
-
●
●
Semi-plan 10X/0.25
-
-
●
●
Semi-plan 40X/0.65, Spring
-
-
●
●
Semi-plan 100X/1.25, Spring, Oil
-
-
●
●
Nosepiece
Quadruple Revolving Nosepiece
●
●
●
●
Stage
Mechnical Stage 150mm x 135mm, Vernier Scale Travel Range 77mm x 50mm with Graduation of 0.1mm,
●
●
●
●

Condenser

Abbe N.A.=1.25, Milled Out to Phase Slide, Built-in Iris Diaphragm and Filter Holder, Vertical Rack and Pinion Focusing with Safely Spot, Height Adjustable
●
●
●
●
Blue, Amber and Green Filter
●
●
●
●
Focusing
Coaxial Coarse and Fine Focusing Knobs, 0.2mm per Rotation with Graduations in 0.002mm Increments, Tension Adjustment Available, with Upper Stopper and Sliding Stopper
●
●
●
●

Light Source
Base with Built-in Halogen Lamp 6V/20W , with Continue Intensity Control, 110V/220V
●
●
●
●
Optional Accessories
Item No.
Eyepiece
WF16X/10mm
EP16a
WF10X/18mm with Pointer
EPg10
Reticle WF10X/18mm
EPr10b
Objective
Plan 4X/0.10
B-OPr4
Plan 10X/0.25
B-OPr10
Plan 25X/0.4
B-OPr25
Plan 40X/0.65, Spring
B-OPr40
Plan 100X/1.25, Spring, Oil
B-OPor100

Attachment
Photo Adapter
MP03
Photo Eyepiece 2.5X
EPHn2.5
Photo Eyepiece 4X
EPHn4
Photo Eyepiece 6.3X
EPHn6.3
CCD
CCD C-Mount
TV02
Dark Field
Dark Field Condenser N.A.=0.83-0.91
C07
Simple Dark Field Stop
DS03

Phase Contrast Attachment

Centering Telescope
EC8
Phase Contrast Condenser for Semi-Plan Phase Contrast Objective
C06a
S-Plan Negative Phase Contrast Objective10X/0.25
B-OSPnr10
40X/0.65
B-OSPnr40
100x/1.25(Oil)
B-OSPonr100
S-Plan Positive Phase Contrast Objective10X/0.25
B-OSPpr10
40X/0.65
B-OSPpr40
100x/1.25(Oil)
B-OSPopr100
Phase Contrast Condenser for Plan Phase Contrast Objective
C06
Plan Negative Phase Contrast Objective10X/0.25
B-OPnr10
40X/0.65
B-OPnr40
100x/1.25(Oil)
B-OPonr100
Plan Positive Phase Contrast Objective10X/0.25
B-OPpr10
40X/0.65
B-OPpr40
100x/1.25(Oil)
B-OPopr100
