Fluorescent Microscope Trinocular Head 40 - 1000X with CE A16.1103
| A16.1103 Fluorescence Microscope Specification |
-A |
-B |
-C |
-D |
| Head |
Compensation Free Binocular,30°inclined |
- |
- |
● |
- |
| Compensation Free Trinocular,30°inclined |
- |
- |
- |
● |
| Sliding Binocular,45°inclined |
● |
- |
- |
- |
| Sliding Trinocular,45°inclined |
- |
● |
- |
- |
| Eyepiece |
Wide field WF10X/18mm |
● |
● |
- |
- |
| Wide field WF10X/22mm |
- |
- |
● |
● |
| Objective |
195 Fluorescent Objective |
4X |
● |
● |
- |
- |
| 10X |
● |
● |
- |
- |
| 40X(S) |
● |
● |
- |
- |
| 100(S)Oil |
● |
● |
- |
- |
| Infinity Fluorescent Objective |
4X |
- |
- |
● |
● |
| 10X |
- |
- |
● |
● |
| 40X(S) |
- |
- |
● |
● |
| 100(S)oil |
- |
- |
● |
● |
| Focus System |
Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm. |
● |
● |
● |
● |
| Condenser |
N.A.1.25 Abbe Condenser with Iris Diaphragm&Filter |
● |
● |
● |
● |
| Stage |
Double Layers Mechanical Stage,Stage Size:180x150,Moving Range:75x50 |
● |
● |
● |
● |
| Illumination |
Epi- Illumination |
● |
● |
● |
● |
| Transmission Illumination |
● |
● |
● |
● |
| Light Source |
Upper:Mercury Lamp 220V(110V)/100W Pointer or Digital Display Power Supply Box |
● |
● |
● |
● |
| Halogen Bulb:12V/30W |
● |
● |
● |
● |
| Fluoroscope Box |
B Wave Band |
● |
● |
● |
● |
| G Wave Band |
● |
● |
● |
● |
|
| Optional Accessories |
| Objective |
20X |
| 60X(S) |
| Photography Adapter |
Photography Adapter |
| Fluoroscope Box |
U Wave Band |
| V Wave Band |
|
|
