Monocular Polarized Light Microscope CE A15.1013 For Laboratory Research

Monocular Polarized Light Microscope CE A15.1013 For Laboratory Research

  • High Light

    student compound microscope

    ,

    highest magnification microscope

  • Application
    Research
  • Certification
    CE
  • Illumination
    Halogen Lamp
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A15.1013
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Monocular Polarized Light Microscope CE A15.1013 For Laboratory Research

Monocular Polarized Light Microscope CE A15.1013 For Laboratory Research





 A15.1013 Polarizing Microscope, With features of easy operation, complete functions and economy, it is and ideal instrument in geology, petroleum, coal, chemicals and physic fields. It is also widely used in academic demonstration and research.

--Monocular Head, 45° Inclined, 360° Rotatable
--Strain Free Achromatic Objective
--Round Stage Dia.135mm, 360° Rotatable
--Fixed Analyzer With Optical Compensator
--Polarizer 0~90° Rotatable, Located On Top Of Collector





A15.1013 Polarizing Microscope

Head

Monocular Head, 45° Inclined, 360° Rotatable

Eyepiece

WF10x, With Scale Of Crosshair

Objective

Strain Free Achromatic Objective 4x,10x,40x

Nosepiece

Outward Quadruple Nosepiece

Analyzer

Fixed Analyzer
Bertrand Lens, Sliding In/Out Of Optical Path
Optical Compensator :
--λ Slip, First Class Red
--Optical Compensator : 1/4λ Slip

Working Stage

Round Stage Dia.135mm, 360° Rotatable, Graduation 1° Increment, Minimum Resolution 6', Center Adjustable

Focusing

Coaxial Coarse & Fine Adjustment, Focusing Range 28mm, Fine Focusing Division 0.002mm

Condenser

Abbe Condenser N.A.1.25, WIth Iris Diaphragm & Filter

Polarizer

Polarizer 0~90° Rotatable, Located On Top Of Collector

Illumination

Halogen Lamp 6V20W, Brightness Adjustable
