CMOS USB Digital Microscope Camera Microscope Accessories A59.4205

A59.4205 VGA + Mouse Measuring Digital Camera

Senser

1/3" CMOS, Color

Pixel Size

3.75×3.75µm

Resolution

Screen Ratio: 5:4, 1280*1024
Screen Ratio: 4:3, 1280*960, 1024*768
Screen Ratio: 16:10, 1280*800
Screen Ratio: 16:9, 1280*720

Output Digi

12 Bits

Exposure

Progressive Exposure

SNR

43.9dB

Dynamic Range

>115dB

Sensititive (550nm)

5.48V/lux-sec

FPS Max

30fps

Data Interface

VGA, SD Card, U Disk

Power Supply

DC 12V

Max Power

5W

Working Temperature

-10°C to +50°C

Lens Mount

Standard C/CS Mount, Adjustable

Storage

SD Card, U Disk
Picture in JPEP Format
Video in H.264 Format

External Triggering

External Triggering Function Available

Connection

Mouse, Keyboard, U Disk, or Movable Storage Device

Basic Function

Built-in Software Will Auto Start When Connect to VGA Monitor:
--Frezze
--Auto White Balance
--Auto Exporsure
--Four Adjustable Color, p
--Crosshair On Position Display
--Horizontal And Vertical Ruler
--Basic Parameters Of Camera Adjustable
--Contrast, Brightness, Saturation, Hue, Sharpness, Gamma Adjustable
--Taking Photoes, Replay Photoes

Measuring Funtion

--Length Between Spots
--Length Between Spot and Line
--Length Between Lines
--Center Distance
--Arcs
--Circles
--Angles
--Polygons
--Measurement
--Local Magnifier Function
--Scaling Function
--Auto Vertical, Horizontal
--Seeking Critical Point function.
