Infinity 5.0 M Digital Optical Microscope USB output with Halogen Lamp CE A31.0908

Infinity 5.0 M Digital Optical Microscope USB output with Halogen Lamp CE A31.0908

  • Highlight

    portable digital microscope

    ,

    optical microscope with digital camera

  • Applications
    Laboratory
  • Certification
    CE
  • Drawtube
    Trinocular
  • Illumination
    LED
  • Max Magnification
    1000X
  • Theory
    Digital Optical Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A31.0908
  • Document
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Infinity 5.0 M Digital Optical Microscope USB output with Halogen Lamp CE A31.0908


Infinity Plan Digital Optical Microscope Koehler Illumination Microscopes CE A31.0908

 Description:

■5.0M Camera Built-in Digital Head, USB2.0 Output
■Infinity color corrected optical system, new upgraded Koehler illumination system, presents a clear & bright micro-image under each magnification.
■ Fire-new ergonomic design, steady system structure, easy operation, is suitable for various working environments.
■"Building blocks" design for combining multiple functions, fluorescence, phase contrast, polarizing, dark field attachments can be assembled on the basis of bright field observation.
■Widely apply to clinical diagnosis, teaching experiment, pathological test and other micro-fields.




Specifications:


A31.0908 Specification

Optical system

Infinity color corrected optical system

Digital Camera

5.0M, COMS Digital Camera, USB2.0 output.

Head

Compensation trinocular head, 30 inclined, 360 rotatable,
interpupillary distance 54-75mm;splitting ratio R:T=100:0 or
 0:100; diopter +/-5 adjustable.

Eyepiece

High eye-point wide field plan eyepiece PL10x22mm,
reticle can be assembled.

Objective

Infinity plan achromatic objectives 4x ,WD=7.18mm

Infinity plan achromatic objectives 10x,WD=4.70mm

Infinity plan achromatic objectives 20x ,WD=1.75mm

Infinity plan achromatic objectives 40x (Spring),WD=0.72mm

Infinity plan achromatic objectives 100x (Spring, Oil ),WD=0.15mm

Nosepiece

5 Holes revolving nosepiece, inward

Focusing

Coaxial focus system with upper limited and tension adjustment; coar
se range: 25mm; fine precision: 0.002mm; focus height adjustable.

Stage

175x145mm double layer mechanical stage, rotatable; with special fa
brication processing, anti-corrosive and anti-friction; X,Y moving hand
wheel in right or left hand; moving range: 76x50mm, precision : 0.1m
m.

Condenser

N.A.1.2/0.22 swing-out type achromatic condenser

Light Source

6V/30W halogen, pre-centered, intensity adjustable.

Filter

Blue

Optional Accessories


Eyepiece

High eye-point PL10x/22mm with micrometer, diopter adjustable

High eye-point PL15x/16mm

Objectvie

Infinity plan achromatic objectives 2x

Nosepiece

4 Holes revolving nosepiece, inward

Phase Contrast Attachement

Infinity plan phase contrast objectives 10X,WD=4.70mm

Infinity plan phase contrast objectives 20X,WD=1.75mm

Infinity plan phase contrast objectives 40X,WD=0.72mm

Infinity plan phase contrast objectives 100X,WD=0.15mm

N.A.1.25 five holes phase contrast condenser(Infinity)

Centering Telescope

Filter

Polarizing Attachment

Polarizer

Analyzer 360rotatable;

Slide

Rotatable Working Stage

polarizer and analyzer can be out of light path.

Dark Field Condenser

N.A.0.9dry

N.A.1.25immersion

CCD adapter

1x C-Mount,Focus Adjustable

0.50x, For 1/2 C-Mount,Focus Adjustable

0.67x, For 2/3 C-Mount,Focus Adjustable
