Fiber Optical microscope light source Microscope Accessories A56.0600

Fiber Optical microscope light source Microscope Accessories A56.0600

  • High Light

    compound microscope parts

    ,

    parts of the microscope

  • Applications
    Microscope
  • Certification
    CE
  • Product Name
    Microscope Accessories
  • Power Consumption
    150W
  • Input Current
    1.5A
  • Output Current
    1.5-7.5A
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A56.0600
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Fiber Optical microscope light source Microscope Accessories A56.0600



Description:


--Modular design for easy replacement of bulb, socket and computer board.
--Quick release of fiber optic cables for multiple light application requirements.
--Entire plastic housing, light in weight.
-- Built-in aluminum alloy guard plate to prevent excessive heat from hurting the user.





Specifications:



A56.0600 Fiber Optical Cold Light Source

A56.0600-01

Fiber Optical Cold Light Source Main Body
Power Consumption 150W
Input Current 1.5A
Output Current 1.5-7.5A
Fuse 2A
Startup Time 2s (Full Load)
Efficiency 85-95%
Operating Temperature 0-45℃
Storage Temperature -25-85℃
Relative Humidity 85%
Illumination ≥100000 Lux
Color Temperature ≥3000K
Spectrum Range 450-700nm
Dimensions(L×W×H) 8.19"×4.13"×4.88" (208mm×105mm×124mm)
Lamp 21V 150W halogen bulb
Service Llife of Lamp Approx. 200 hours at full load
Weight 3kg (6.6 lbs.)
Adapter With a 5/8" Fiber Optic Cable Adapter



A56.0600-02

Red, Dark Blue,Green Filters Kit
Note: Light blue filter for Daylght correction (standard unit)

A56.0600-03

Single Pipe Light Guide
With focusing lens, fiber dia.: 6mm; 18" (460mm) gooseneck.

5/8" standard adapter is for attaching the Fiber Optic Illuminator.

A56.0600-04A

Dual Pipe Light Guide
Fiber Optic Goose Neck Dual Pipe without focusing lens, fiber dia.:

7.1mm; 800mm in length. 5/8" standard adapter is for attaching to

the Fiber Optic Illuminator.

A56.0600-04B

Dual Pipe Light Guide
Fiber Optic Goose Neck Dual Pipe without focusing lens, fiber dia.:

 7.1mm; 460mm in length. 5/8" standard adapter is for attaching to

 the Fiber Optic Illuminator.

A56.0600-05

Ring Light Guide
Ring's I.D.: 58mm; Fiber Dia.: 10mm, with PVC tubing at 1m in length,

fitting most major brand microscopes. 5/8" standard adapter is for

attaching to Fiber Optic Illuminator.
◇ 360°Shadow-Free, Cool, Uniform Illumination
◇ Accepts Polarizer Accessories
◇ PVC-Covered Metal Sheathing
◇ Black Anodized Aluminum Housing
◇ 70% Typical Illuminator Coupling Efficiency
◇ Glass Fibers with Ground & Polished End-Faces

A56.0600-08

Ring Light Guide
Ring's I.D.: 65mm; Fiber Dia.: 11mm, with PVC tubing at 1m in length,

fitting most major brand microscopes. 5/8" standard adapter is for attaching

 to Fiber Optic Illuminator.
◇ 360°Shadow-Free, Cool, Uniform Illumination
◇ Accepts Polarizer Accessories
◇ PVC-Covered Metal Sheathing
◇ Black Anodized Aluminum Housing
◇ 70% Typical Illuminator Coupling Efficiency
◇ Glass Fibers with Ground & Polished End-Faces

A56.0600-06

Back Light Guide
Used to silhouette opaque objects or for imaging through transparent

objects, perfect for metrology or plastic applications.
4"×4" active area, 178×110×20mm dimension, fiber dia.: 10mm. 5/8"

standard adapter is for attaching to the Fiber Optic Illuminator.

A56.0600-07

Replacement Halogen Bulb
21V150W Halogen Bulb
