Bright Field Jewelry Microscope 20X For Research A24.0901

China Bright Field Jewelry Microscope 20X For Research A24.0901 supplier
Bright Field Jewelry Microscope 20X For Research A24.0901 supplier Bright Field Jewelry Microscope 20X For Research A24.0901 supplier Bright Field Jewelry Microscope 20X For Research A24.0901 supplier Bright Field Jewelry Microscope 20X For Research A24.0901 supplier

Large Image :  Bright Field Jewelry Microscope 20X For Research A24.0901

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A24.0901

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Applications: Research, Diamond, Gems Certification: CE, Rohs
Drawtube: Binocular Illumination: Halogen Lamp, LED
Magnification: 20X Theory: Jewelry Microscope




Description:



A24.0901 Jewelry Microscope 0.67~4.5x, has specially designed accoring to jewelry work. Fully meet the appraisal needs of all kinds of diamonds, crystals, gems and other jewelries.
--0.67~4.5x Zoom Lens, with WF10x/22mm Eyepiece,
--Total Optical Magnification 6.7~45x
--Professional Jewelry Microscope Stand, With Base Rotating and Inclination Adjustable
--Bright Field Transmit, Reflect, Polarizing and Dark Field Observation
--Upper Illumniation 7W Fluorescent or 1W LED, Transmit Illumination 6V30W Halogen Lamp
--Fully Coated Optical System, Sharp & Clear Image





Specifications:



A24.0901 Jewelry Microscope, 0.67x-4.5x Specification

Observation Ways

Bright Field Transmit, Reflect, Polarizing and Dark Field Observation

Head

Brinocular, 45° Inclined, 360° Rotatable, +/-5° Diopter Adjustable,

 Interpupillary Adjustment 54~75mm

Zoom Range

0.67~4.5x

Zoom Ratio

1:6.7

Eyepiece

WF10x/22mm, Both with Eye-cup

Magnification

6.7~45x, Up to 2~225x with Auxiliary Lens

Working Distance

100mm, With Standard 1x Lens. Up to 26~287mm With Auxiliary Lens

Gem Clamp

Wire Clamp For Bigger Objects, Flat Clamp For Smaller Objects

Stand

Professional Jewelry Microscope Stand, With Base Rotating and

 Inclination Adjustable, with Built-in Dark Field, Polarizing Device

Illumination

Upper Illumniation 7W Fluorescent or 1W LED
Transmit Illumination 6V30W Halogen Lam

A24.0901 Jewelry Microscope, 0.67x-4.5x Optional Accessories



Eyepiece

WF15x/15mm

A51.0923-15

WF20x/10mm

A51.0923-20

WF25x/9mm

A51.0923-25

Auxiliary Lens

0.3x, W.D. 287mm

A52.0928-03

0.4x, W.D. 217mm

A52.0928-04

0.5x, W.D. 177mm

A52.0928-05

0.75x, W.D. 117mm

A52.0928-75

1.5x, W.D. 47mm

A52.0928-15

2.0x, W.D. 26mm

A52.0928-20



Bright Field Jewelry Microscope 20X For Research A24.0901Bright Field Jewelry Microscope 20X For Research A24.0901Bright Field Jewelry Microscope 20X For Research A24.0901Bright Field Jewelry Microscope 20X For Research A24.0901
