40X - 400X Metallurgical Polarizing Light Microscope WF10X - 18mm A15.2603

40X - 400X Metallurgical Polarizing Light Microscope WF10X - 18mm A15.2603

  • High Light

    student compound microscope

    ,

    compound light microscope

  • Application
    Laboratory, Metal
  • Certification
    CE, Rohs
  • Drawtube
    Binocular
  • Illumination
    Halogen Lamp
  • Magnification
    40X - 400X
  • Theory
    Polarizing Light Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A15.2603
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

40X - 400X Metallurgical Polarizing Light Microscope WF10X - 18mm A15.2603



Specifications:



Specification

A15.2603-A

A15.2603-B

Head

Binocular,Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.

Trinocular, Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.

Eyepiece

WF10X/18mm

WF10X/18mm, with micrometer 0.1mm/Div

Objective

Infinity Stress Free Plan Objective 4x/0.10

Infinity Stress Free Plan Objective 10x/0.25

Infinity Stress Free Plan Objective 20x/0.40(S)

Infinity Stress Free Plan Objective 40x/0.65(S)

Nosepiece

Quadruple, Center Adjustable

Stage

Round stage, Rotatable 360°, Center Adjustable, Division 1°, Vernier Division 6'

Condenser

Abbe N.A. 1.25, with Iris Diaphragm, Stress Free

Focusing

Coaxial coarse and fine focusing knob

Polarizing Set

Analyzer 0-90°, It Can Be Moved Out of the Optical Path for Single Polzrizing Observe

built-in Bertrand Llens, Center Adjustable

λ Plate,First Class Red

λ/4 Plate

Quartz Wedge Plate, I-IV Class

Poalizer

Filter

Blue

Light Source

6V 20W Halogen Lamp, Brightness Adjustable

6V 30W Halogen Lamp, Brightness Adjustable

Optional Accessories
Item No.
Objective Infinity Stress Free Plan Objective 60x/0.8(S) A5P.2630-60
Stage Polarizing Attached Mechanical Stage A5P.2616
Light Source Upgrade to 6V 30W A56.2650
Filter
Green A56.2616-SG
Neutral A56.2616-SN
Yellow A56.2616-SA
Adapter CCD Adapter 0.47x A55.2601-S47
CCD Adapter 1.0x A55.2601-S10



40X - 400X Metallurgical Polarizing Light Microscope WF10X - 18mm A15.2603 040X - 400X Metallurgical Polarizing Light Microscope WF10X - 18mm A15.2603 1
