OPTO- EDU A36.4952 Mini Digital LCD HD Scanning Electron Microscope With Best Price
A36.4952 combined the traditional optical and eletronic video technology , completely solves the disadvantage of the traditional microscope, which is easy to cause human fatigue when observed for a long time.A36.4962 integrates magnification imaging ,monitor and LED lights into one. It is designed for fast and efficient observation of details
| A36.4952 HD Digital Microscope | |
| Hardware Configuration | |
| Image Sensor | Aptina AR0330 CMOS Sensor |
| Expose Mode | Rolling Shutter |
| Maximum Resolution | 3.5M 2304*1536 (3,538,944 Pixels) |
| Sensor Optical Format | 1/3'' (5.07mm(H)*3.38mm(V), Diagonal 6.09mm) |
| Pixel Size | 2.2μm*2.2μm |
| Dynamic Range | 69.5dB |
| SNR(Signal Noise Ratio) | 39dB |
| Spectral Characteristics | 380-650nm |
| Exposure Capability | Real-time auto, Single auto, Manual Adjustment |
| White Balance | Real-time Auto, Single Auto, Manual Adjust R G B separately |
| Display (preview ) Resolution | HD:1920*1080i60, 1920*1080P30, 1280*720P60, 640*480P60(Auto fit by monitor ) |
| Record Format |
Snapshot Picture Format: JPG Resolution: HD: 2304*1536, 2304*1296, 1920*1080, 1280*720, 800*480 Record Resolution: HD: 1280*720@30FPS, 800*480@30FPS |
| Record Route | HD: TF card (Maximum support 64G) |
| Power Supply | Power adapter: Input:AC 100~240V/50~60Hz;DC 12V/5A/60W |
| Monitor: USB-A-Output:DC5V/2A×3 | |
| Lens Specifications | ||
| Total Magnification | 8.8x~480x (including digital magnification) | |
| Optical Magnification | 0.7×~5× Optical Zoom Lens | |
|
Optical Resolution(um)
|
When in 0.7× 16.78um | When in 3× 6.10um |
| When in 1× 11.18um | When in 4× 4.79um | |
| When in 2× 8.39um | When in 5× 4.79um | |
| Monitor Parameters | |
| Size | 12.5” |
| Type | a-Si TFT-LCD/IPS |
| Resolution | 1920×1080 |
| Color Display | 16.7M |
| Brightness | 300 Nit |
| Contrast | 800:1 |
| Visible Angle | 170° horizontal&vertical |
1. It has unique manual focus knob on top pf camera helps you to product the sharpest image within the working distance (0mm~232.5mm) when the observation object size changed from small to large. Avoid tedious adjustment work and directly change the working distance through eye-height adjustment ring and expand the original magnification ratio of the microscope .
2. With the factory integrated 3.5MP 1080i 60fps digital camera and HD lens
3. Easy to realize continuous zoom to overall magnification of 8.8X~480X (based on 12.5’ monitor)
4. A36.4952 is equipped with the external coaxial light, which can uniformly illuminate the surface of the plane and the shiny surface , and enhance the features of marking , recessing or embossing. It can highlight the uneven surface of the object, overcome the interference caused by the reflection of the surface , and improve the microscope reproducibility.
5. Outstanding ergonomics design with 360° universal shaft bracket, to hover randomly. It is flexible and easy to use, convenient for operator to view from different angles. Free up the operator’s head and body , the work efficiency can be improved and fatigue can be reduced effectively .
6. Integrated solution -one device can achieve multiple function of low magnification tasks; Equipped with all-in-one 12.5’ monitor, when needed, operator can fine-tune screen angle to look up ( max 90 °) or look down (max 24°)
7.Simple ,easy to use image and video capture software is included as standard to allow you to use it instantly .
