WF10X Double Layers Mechanical Stage Biological Microscope A11.1316 With LED Lamp 1W Light Source

WF10X Double Layers Mechanical Stage Biological Microscope A11.1316 With LED Lamp 1W Light Source

  • High Light

    binocular biological microscope

    ,

    biological compound microscope

  • Certification
    CE|Rohs
  • Applications
    Student|school|Laboratory|Hobby
  • Condenser
    Abbe Condenser N.A.1.25
  • Illumination
    LED Lamp 1W
  • Magnification
    1000X
  • Product Name
    Biological Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Model Number
    A11.1316
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

WF10X Double Layers Mechanical Stage Biological Microscope A11.1316 With LED Lamp 1W Light Source



WF10X Double Layers Mechanical Stage Biological Microscope A11.1316 With LED Lamp 1W Light Source





Specifications:

A11.1316 Biological Microscope
M
B
T
Head
Monocular Head, 30° Inclined, 360° Rotatable


Sliding Binocular Head, Interpupillary Distance:55-75mm, 45° Inclined, 360° Rotatable, Left & Right Diopter Adjustable


Sliding Trinocular Head, Interpupillary Distance:55-75mm, 45° Inclined, 360° Rotatable, Left & Right Diopter Adjustable


Eyepiece
Wide Field Plan WF10X
Objective



Achromatic 4X
Achromatic 10X
Achromatic 40X(S)
Achromatic 100X(S,Oil)
Nosepiece
Quadruple Nosepiece
Stage
Double Layers Mechanical Stage 140X155mm/75X50mm
Condenser
Abbe Condenser N.A.1.25, Φ2-Φ30mm Iris Diaphragm,With Φ32 Filter Holder
Focusing
Coaxial Coarse & Fine Focusing Adjustable Mechanism 25mm,Precision 0.002mm
Light Source
LED Lamp 1W, Brightness Adjustable
Weight
Gross Weight 7Kg, Net Weight 6Kg
Package
1 Set/ Carton, 33cm*28cm*43cm, Wood Cabinet Is Optional
A11.1316 Optional Accessory
Eyepiece
Wide Field Plan WF16X
A51.1303-16
