Laboratory Compound Optical Microscope with Infinity Trinocular Head







A12.0908 Laboratory Microscope, newly developed in 2013.
--Infinity Color Corrected Optical System With Newly Upgraded Koehler Illumination System, Presents Clear & Bright Micro-image Under Each Magnification.
--Fire-new Ergonomic Design, Steady System Structure, Easy Operation, Suitable For Various Working Environments.
--Building Blocks Design For Combining Multiple Functions, Fluorescence, Phase Contrast, Polarizing, Dark Field Attachments Can Be Assembled On The Basis Of Bright Field Observation.
--Widely Apply To Clinical Diagnosis, Teaching Experiment, Pathological Test And Other Micro-fields.
--Newly Designed Integrative Y-Shape Body, All Metal Diecasted Under High Pressure. High stability, No Image Dithering Under High Magnification Observation, Ensures The Test Precision Of Multi-channel Fluorsecnce Diagnosis.





A12.0908 Specification A B
Optical system Infinity color corrected optical system • •
Head Compensation Trinocular Head
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Diopter +/-5 Adjustable.		 • -
Compensation Trinocular Head
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Splitting Ratio R:T=100:0 or 0:100, Diopter +/-5 Adjustable.		 - •
Eyepiece High eye-point wide field plan eyepiece PL10x22mm, reticle can be assembled.
Objective Infinity Plan Achromatic Objectives
4x ,WD=7.18mm
10x,WD=4.70mm
20x ,WD=1.75mm
40x (Spring),WD=0.72mm
100x (Spring, Oil ),WD=0.15mm
Nosepiece 5 Holes revolving nosepiece, inward
Focusing Coaxial Focus System With Upper Limited And Tension Adjustment; Coarse Range: 25mm; Fine Precision: 0.002mm; Focus Height Adjustable.
Stage Double Layer Mechanical Stage 175x145mm, With Special Fabrication Processing, Anti-corrosive And Anti-friction; X/Y Moving Hand Wheel In Right Or Left Hand; Moving Range 76x50mm, Precision 0.1mm
Condenser N.A.1.2/0.22 Swing-out Type Achromatic Condenser
Light Source 6V/30W Halogen, Pre-centered, Intensity Adjustable.
Filter Blue
Optional Accessories
Eyepiece High Eye-point PL10x/22mm with Micrometer, Diopter Adjustable A51.0905-1022R
High Eye-point PL15x/16mm A51.0903-1516
Objectvie Infinity plan achromatic objectives 2x A52.0902-2
Nosepiece 4 Holes revolving nosepiece, inward A54.0930-BS4
Phase Contrast Attachement Infinity Plan Phase Contrast Objectives 10X,WD=4.70mm A5C.0937-10
Infinity Plan Phase Contrast Objectives 20X,WD=1.75mm A5C.0937-20
Infinity Plan Phase Contrast Objectives 40X,WD=0.72mm A5C.0937-40
Infinity Plan Phase Contrast Objectives 100X,WD=0.15mm A5C.0937-100
N.A.1.25 Five Holes Phase Contrast Condenser (Infinity) A5C.0912-PCI
Centering Telescope A5C.0910-30
Polarizing Attachment Polarizer (ø45), Can Be Out Of Light Path. A5P.0923-P
Analyzer 360° Rrotatable,Can Be Out Of Light Path. A5P.0923-A
λ Slide A5P.0923-C1
Rotatable Working Stage A5P.0923-RW
Dark Field Condenser N.A.0.9 Dry A5D.0912-D
N.A.1.25 Immersion A5D.0912-W
Reflected Fluorescence System 6-Holes Disc Reflected Fluorensent Illumination A12.0908 + Fluorescent Upgrade to A16.0908

A12.0908 + Fluorescent + CCD Camera Upgrade toA16.0909
Mercury Lamp House 100W/DC
Mercury Lamp Power 100V-240V AC With Indicator Display
Eye Protecting Board
HBO Ultra Hi-Voltage Spherical Mercury Lamp 100W/DC OSRAM
Fluorescence Filter System B
Fluorescence Filter System G
Fluorescence Filter System UV
Fluorescence Filter System V A5F.0923-V1
Filter Yellow Filter, Dia.45mm A56.0935-XYY
Green Filter, Dia.45mm A56.0935-XYG
Netural Filter, Dia.45mm A56.0935-XYG
Attenuation Plate, Transmission 25% A5F.0925-50R
CCD Adapter 1x C-Mount, Focus Adjustable A55.0926-10
0.50x, For 1/2” C-Mount, Focus Adjustable A55.0926-50
0.67x, For 2/3” C-Mount, Focus Adjustable A55.0926-67
Series of Microscope Metallurgical Microscope A13.0909
Polarizing Microscope A15.0908
Fluorescence Microscope, APO A16.0908
Digital Fluorescence Microscope, APO A16.0909
