Infinity Industry Monocular / Trinocular DIC Metallurgical Optical Microscope A13.0217
A13.0217 DIC Metallurgical Microscope, used for biology medicine agriculture and industry area widely. It is the ideal instrument in medical treatment, teaching demonstration and scientific research.
--High Quality Infinity Opitcal System
--Monocular, Trincular Head Optional
--DIC Slide For 5x/10x/20x Objective
--Strainfree Infinity LWD Plan Achromatic 5x,10x,20x Optional
--Polarizing System, Switch In/Out Of Light Path
|
A13.0217 DIC Metallurgical Microscope
|
A
|
B
|
| System |
Infinity Optical System, Total Magnification 100x |
| Mechanical Tube Length ∞ |
| Objective Conjugate Distance∞ |
|
Head
|
Monocular |
o
|
|
|
Trinocular Head, 30° Inclined, Light Separate Ratio 80:20
|
|
o
|
|
Eyepiece
|
WF10x/18mm, Eyepiece Tube Dia.23.2mm, Parfocal Distance 10mm
|
| Objective |
Strainfree LWD Infinity Plan Achromatic PL10x/0.25, W.D.20.2mm |
| Working Stage |
Double Layer Mechanical Stage 180*145mm, Moving Range 35*30mm |
| Focusing |
Coaxial Coarse & Fine Focus Knob, Tension Adjustable, Minimum Division 0.002mm, Height Adjustabout 133mm, Max Sample Height 130mm |
| DIC |
DIC Slide Match 5x/10x/20x Objectives, Horizontal Adjustable |
| Polarizing |
Polarizer, 360° Rotatable, Switch In/Out |
| Analyser, Switch In/Out |
| Light Source |
Coaxial Illumination, High Light LED, Brightness Adjustable |
| Power |
Wide Range Voltage 85~265V, 50/60Hz |
|
Optional Accessories
|
| Eyepiece |
WF15x/11mm |
A51.0203-16A |
| |
WF20x/11mm |
A51.0203-20A |
| Objective |
Strainfree LWD Infinity Plan Achromatic PL5x/0.1,W.D.18.2mm |
A5M.0235-5A |
| Strainfree LWD Infinity Plan Achromatic PL20x/0.4,W.D.8.8mm |
A5M.0235-20 |
| Adapter |
CCD Adapter 0.4x |
A55.0202-01 |
| CCD Adapter 0.5x |
A55.0202-04 |
| CCD Adapter 1.0x |
A55.0202-02 |
| CCD Adapter 0.5x With Dividing 0.1mm/Divv |
A55.0202-03 |
| Digital SLR Camera Adapter for Canon EF Series |
A55.0204-02 |
|
