Gem Trinocular Stereo Zoom Microscope 7x - 45x A23.0902-ST2

Gem Trinocular Stereo Zoom Microscope 7x - 45x A23.0902-ST2

  • High Light

    stereo dissecting microscope

    ,

    stereo binocular microscopes

  • Magnification
    7x - 45x
  • Applications
    Industry|Gem|Medical
  • Certification
    CE|Rohs
  • Drawtube
    Binocular|Trinocular
  • Product Name
    Stereo Zoom Microscope
  • Theory
    Stereo Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A23.0902-ST2
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Gem Trinocular Stereo Zoom Microscope 7x - 45x A23.0902-ST2



Gem Trinocular Stereo Zoom Microscope 7x - 45x A23.0902-ST2



Description:



--0.7~4.5x Zoom Lens, with WF10x/20mm Eyepiece,
--Total Optical Magnification 7~45x
--Big Square Pole Stand, No Light Source





Specifications:



A23.0902-ST2 Zoom Stereo Microscope Specification

B1

T1

Head

Binocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

 Interpupillary Adjustment 54-75mm

o

Trinocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

 Interpupillary Adjustment 54-75mm

o

Eyepiece

WF10x/22mm, High Eyepoint

Zoom Lens

0.67~4.5x

Zoom Ratio

1:6.7

Magnification

6.7x~45x, (2x~225x with Auxliliary Objective)

Working Distance

100mm, With Auxiliary Objectives 26~287mm

Light Source

No Light Source

Stand

Big Pole Stand, Height 248mm,, Base 260*320*12mm

A23.0902-ST2 Zoom Stereo Microscope Optical Data Sheet

Auxiliary Lens

0.3x

0.4x

0.5x

0.75x

1.0x

1.5x

2.0x

Working Distance

287mm

217mm

177mm

117mm

100mm

47mm

26mm

WF 10x

Magnification

2.0-13.5x

2.7-18.0x

3.4-22.5x

5.0-33.8x

6.7-45.0x

10.1-67.5x

13.4-90.0x

View Field(mm)

109.5-16.3

82.1-12.2

65.7-9.8

43.8-6.5

32.8-4.9

21.9-3.3

16.4-2.4

WF 15x

Magnification

3.0-20.3x

4.0-27.0x

5.0-33.8x

7.5-50.6x

10.1-67.5x

15.1-101.3x

20.1-135x

View Field(mm)

79.6-11.9

59.7-8.9

47.8-7.1

31.8-4.7

23.9-3.6

15.9-2.4

11.9-1.8

WF 20x

Magnification

4.0-27.0x

5.4-36.0x

6.7-45.0x

10.1-67.5x

13.4-90.0x

20.1-135.0x

26.8-180x

View Field(mm)

59.7-8.9

44.8-6.7

35.8-5.3

12.9-2.4

17.9-2.7

11.9-1.8

9-1.3

WF 25x

Magnification

5.0-33.8x

6.7-45.0x

8.4-56.3x

12.6-84.4x

16.8-112.5x

25.1-168.8x

33.5-225x

View Field(mm)

44.8-6.7

33.6-5.0

26.9-4.0

17.9-2.7

13.4-2.0

9.0-1.3

6.7-1.0



A23.0902-ST2 Zoom Stereo Microscope Optional Accessories

Cata. No.

Head

Binocular Head + WF10x/20mm

A23.0902-BH

Trinocular Head + WF10x/20mm

A23.0902-TH

Eyepiece

WF10x/20mm, High-eyepoint, Outside Dia. 30mm

A51.0923-10

WF15x/15mm, High-eyepoint, Outside Dia. 30mm

A51.0923-15

WF20x/10mm, High-eyepoint, Outside Dia. 30mm

A51.0923-20

WF10x/20mm,with Reticle

A51.0933-10

WF15x/15mm,with Reticle

A51.0933-15

WF20x/10mm,with Reticle

A51.0933-20

Auxiliary Lens

0.5X,W.D. 165mm

A52.0928-05

0.75X,W.D. 105mm

A52.0928-75

1.5X,W.D. 45mm

A52.0928-15

2.0X,W.D. 30mm

A52.0928-20

CCD Adapter

0.50x, For 1/2" CCD

A55.0933-1/2

0.35x, For 1/3" CCD

A55.0933-1/3
