40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028

China 40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028 supplier
40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028 supplier 40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028 supplier

Large Image :  40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028

Product Details:

Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE, Rohs
Model Number: A16.1028

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Contact Now
Detailed Product Description
Application: Research, Learning Certification: CE, Rohs
Drawtube: Trinocular Illumination: Halogen Lamp
Magnification: 40x - 1000x Theory: Fluorescence Microscope



40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028



Specifications:



A16.1028 Fluorescent Microscope
Head
Seidentopf Trinocular Head, at 30°, 360° Rotatable, interpupillary 48-75mm
Eyepiece
Hight point and extra Wide Field EWF10X/20, eyepiece tube Dia:30mm
Nosepiece
Backward Quintuple Nosepiece
lnfinity plan achromatic objective
Infinity plan achromatic 4X
Infinity plan achromatic 10X
Infinity plan achromatic 40X
Infinity plan achromatic 100X
Stage
Double Layers Mechanical Stage 185x142mm, Moving Range 75x55mm

Condenser

Swing condenser N.A.0.9/0.25
Focusing
Coaxial Coarse & Fine Focus Adjustment
Kohler illumination
External lllumination,Asperical collector,Halongen Lamp 12v30w
Optional Accessories
Item No.
lnfinity Plan Achromatic Objective
Infinity plan achromatic 20X A52.1006-20
Video Adapter C Mount 1x A55.1002-10
C Monut 0.5x A55.1002-05
Turret phase contrast kit A5C.1003



A5F.1002-BG Epi-fluorescent Attachment Specification
40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028
Reflected illumination
  Excitation Dichroic Mirro Barrier filter
B(Blue)excitation filter system BP460-490
DM500
BA520
*
G(Green)excitation filter system BP510~550
DM570
BA590
*
U(Ultraviolet) excitation filter system BP330-385
DM400
BA420
O
V(Violet) excitation filter system BP400-410
DM455
BA455
O
Lamp 100WHBO Ultra Hi-voltage Spherical Mercury Lamp
*
Protection Barrier Barrier to Resist the Ulraviolet Light
*
Power Supplier Power Supplier NFP-1,220V/110V interchangeable, Digital Display
*
Fluorescent Objective

Infinity Plan Fluorescent objective 4x

O
Infinity Plan Fluorescent objective 10x
O
Infinity Plan Fluorescent objective 20x
O
Infinity Plan Fluorescent objective 40x
O
Infinity Plan Fluorescent objective 100x
O
Immersion Oil Fluorescence Free Oil
*
Neutral ND25 filter
O
Centering Plate
O
Note: * means standard parts O means optional parts






40x - 1000x Epi - Fluorescence Microscope Trinocular A16.1028
