Dark Field Compound Optical Microscope Trinocular With Blue / Green Filter CE A12.1008
Specifications:
|
A12.1008 Biologcial Microscope
|
A
|
B
|
|
|
Head
|
Siedentopf binocular head, inclined at 30°, 360° Rotatable |
●
|
|
| Siedentopf trinocular head, inclined at 30°, 360° Rotatable |
●
|
||
|
Eyepiece
|
Wide field eyepiece WF10x/ 20 | ||
|
Objective
|
Semi-plan Achromatic Objective 4x | ||
| Semi-plan Achromatic Objective 10x | |||
| Semi-plan Achromatic Objective 40x | |||
| Semi-plan Achromatic Objective 100x | |||
|
Nosepiece
|
Backward quadruple nosepiece | ||
|
Stage
|
Double Layers Mechanical Stage 140×140mm/ 75×50mm | ||
|
Condenser |
Abbe condenser N.A.1.25 with Iris diaphram & filter | ||
|
Filter
|
Blue filter | ||
| Green filter | |||
|
Illumination
|
Halogen lamp 6V/ 20W, brightness adjustable | ||
|
Optional Accessories
|
Item No.
|
|
|
Eyepiece
|
Wide Field Eyepiece WF16x/ 11 |
A51.1002-16
|
|
Objective
|
Plan Achromatic Objective 4x |
A52.1004-4
|
| Plan Achromatic Objective 10x |
A52.1004-10
|
|
| Plan Achromatic Objective 20x |
A52.1004-20
|
|
| Plan Achromatic Objective 40x |
A52.1004-40
|
|
| Plan Achromatic Objective 60x |
A52.1004-60
|
|
| Plan Achromatic Objective 100x |
A52.1004-100
|
|
|
Nosepiece
|
Quintuple nosepiece |
A54.1001-5M
|
|
Illumination
|
Kohler illumination |
A56.1005-3
|
|
Photo Attachment
|
A55.1001
|
|
|
Video Attachment
|
C Mount 1x |
A55.1001-10
|
| C Mount 0.5x |
A55.1001-05
|
|
|
Epi-fluorescent Attachment
|
A5F.1001
|
|
|
Phase Contrast Attachment
|
Simple phase contrast set | A5C.1001 |
| Sliding phase contrast set | A5C.1002-C3 | |
| Turret phase contrast set | A5C.1003-B1 | |
|
Polarization Set
|
Simple polarization set | A5P.1001 |
|
Dark Field Condensor
|
Dark field condenser (Dry) N.A. 0.9 | A5D.1001-BD |
| Dark field condenser (Immersion) N.A. 1.25-1.36 | A5D.1001-BO | |
