Specifications:
|
A11.1117 Biological Microscope
|
-A
|
-B
|
|
|
Head
|
Compensation Free Binocular,30°inclined,55mm-75mm |
●
|
-
|
| Compensation FreeTrinocular,30°inclined,55mm-75mm |
-
|
●
|
|
|
Eyepiece
|
WF10X/18mm |
●
|
●
|
|
Objective
|
Achromatic 4X |
●
|
●
|
| Achromatic 10X |
●
|
●
|
|
| Achromatic 40X, Spring |
●
|
●
|
|
| Achromatic 100X, Spring,Oil |
●
|
●
|
|
|
Nosepiece
|
Quadruple Revolving Nosepiece |
●
|
●
|
|
Stage
|
Double Layer Mechanical Stage,Size150mmx150mm,Moving Range:80mmx50mm |
●
|
●
|
|
Focusing
|
Coaxial Coarse and Fine Focusing Scale Value 0.002mm, Focusing Range :30mm |
●
|
●
|
| Condenser | ABBE N.A.1.25Condenser with Iris Diaphragm & Filter |
●
|
●
|
| Illumination | Kohler Illumination |
●
|
●
|
|
Light Source
|
Halogen Bulb 6V/20W,AC 220V/110V,Brightness Adjustable |
●
|
●
|
|
Optional Accessories
|
||||||
| Eyepiece | WF16X | |||||
| WF20X | ||||||
| P16X | ||||||
| Objective | Achromatic 20X | |||||
| Achromatic 60X, Spring | ||||||
| Semi-plan Objective 4X | ||||||
| Semi-plan Objective 10X | ||||||
| Semi-plan Objective 20X | ||||||
| Semi-plan Objective 40X(S) | ||||||
| Semi-plan Objective 60X(S) | ||||||
| Semi-plan Objective 100X(S) | ||||||
| Plan Objective 4X | ||||||
| Plan Objective 10X | ||||||
| Plan Objective 20X | ||||||
| Plan Objective 40X(S) | ||||||
| Plan Objective 60X(S) | ||||||
| Plan Objective 100X(S) | ||||||
| Dark Field | Darkfield | |||||
| Photo Adapter | Photo Adapter | |||||
| CCD Adapter | 0.5x | |||||
| 0.57x | ||||||
| 0.75x | ||||||
