Laboratory Inverted Optical Microscope

Laboratory Inverted Optical Microscope

  • High Light

    inverted biological microscope

    ,

    inverted fluorescence microscope

  • Applications
    Laboratory
  • Certification
    CE, Rohs
  • Drawtube
    Binocular
  • Illumination
    Halogen Lamp
  • Product Name
    Inverted Optical Microscope
  • Theory
    Inverted Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A14.2701
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Laboratory Inverted Optical Microscope

Specifications:



Specification

A14.2701 Inverted Microscope

Optical System

UCIS infinity independent achromatic optical system

Frame

One-piece construction from arm to base

Head

Seidentopf binocular head, 45° inclined, interpupillary distance 52-75mm, ±5 diopter adjustment

Eyepiece

WF10x/20mm, plan, high eyepoint up to 21mm,

Centering Attachment

Centering telescope

Objective

Infinity LWD plan achromatic objective 10x/0.25  WD9.67

Infinity LWD plan achromatic objective 20x/0.40  WD7.97,

Infinity LWD plan achromatic objective 40x/0.60  WD3.76

Infinity LWD plan phase contrast objective 20x/0.40  WD7.97

Focus System

Low positioned, coaxial coarse & fine focusing system with adjustable tension control and upper limit stop, minimum reading 1μm, moving range 12mm

Nosepiece

Quintuple, reversed type with positive click stops

Condenser

Abbe condenserN.A. 0.30 with iris diaphragm, with phase contrast slider & filter (φ34) blue,green & yellow, long work distance 72mm

Stage

Right hand controls, low position, mechanical stage, size 240x260mm, moving range 135x85mm.

Drop specimen holder(φ118)

Specimen holder (76x26, φ54)

Light Source

6V30W Halogen lamp house

6V30W Power supply unit

6V30W halogen bulb (Osram)

250V/3.15A Φ5X20 Fuse

Power supply 110-240V,50/60Hz

Phase Contrast

Phase contrast slider for 10x,20x,40x

Adapter

0.5x, C-Mount

Other

Allen screw driver 2mm

Allen screw driver 2.5mm

Dust cover

Power cord

Optional Accessories

Item No.

Head

Seidentopf binocular head, 45° inclined, interpupillary distance 48-75mm, diopter adjustable

A53.2702-1A

Eyepiece

WF10x/22mm plan eyepiece, high eyepoint

A51.2701-10C

WF10x/20mm, plan, high eyepoint up to 21mm, diopter adjustable

A51.2701-10A1

WF16x/13mm, plan

A51.2701-1613

Objective

Infinity plan achromatic objective 4x

A52.2706-04C

Infinity LWD plan achromatic objective 60x

A52.2706-60LB

Infinity LWD plan phase-contrast objective 10x (positive)

A5C.2735-10PB

Infinity LWD plan phase-contrast objective 40x (positive)

A5C.2735-40PB

Infinity LWD Plan Phase-Contrast Objective 10x (Negative)

A5C.2735-10NB

Infinity LWD Plan Phase-Contrast Objective 20x (Negative)

A5C.2735-20NB

Infinity LWD Plan Phase-Contrast Objective 40x (Negative)

A5C.2735-40NB

Stage

Mechanical Stage, Size 350x208mm,Moving Range 50x50mm

A54.2706-5

Adapter

0.25x C-Mount

A55.2701-25A

Digital camera adapter (need to know camera brand)

A55.2702-2

Bulb

6V30W Halogen bulb

A56.2703-30C

Specimen Holder

125x85

A54.2706-3

Fluorescence Attachment

100W DC Mercury lamp house

A5F.2712

Power supply unit for 100W DC mercury lamp

A5F.2713

Epi-fluorescent illumination,multi-functional semi-reflector

A5F.2714

UV (Superior Grade)

A5F.2710-IUV

V (Superior Grade)

A5F.2710-IV

B (Superior Grade)

A5F.2710-IB

G (Superior Grade)

A5F.2710-IG

UV (Common Grade)

A5F.2711-CUV

V (Common Grade)

A5F.2711-CV

B (Common Grade)

A5F.2711-CB

G (Common Grade)

A5F.2711-CG

100W Mercury bulb

A5F.2716-H

100W Mercury bulb (Osram)

A5F.2716-I



Laboratory Inverted Optical Microscope 0Laboratory Inverted Optical Microscope 1Laboratory Inverted Optical Microscope 2Laboratory Inverted Optical Microscope 3
