Infinity Plan LED Fluorescence Microscope 100X - 1000X A16.0907-BL

Infinity Plan LED Fluorescence Microscope 100X - 1000X A16.0907-BL

  • High Light

    inverted fluorescence microscope

    ,

    epifluorescence microscope

  • Application
    Research, Learning, Laboratory
  • Certification
    CE, Rohs
  • Drawtube
    Binocular, Trinocular
  • Illumination
    LED
  • Magnification
    100X - 1000X
  • Theory
    Fluorescence Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A16.0907-BL
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Infinity Plan LED Fluorescence Microscope 100X - 1000X A16.0907-BL


Description:

--Single Band LED Professional Fluorescent Microscope
--Infinity Plan Optical System
--Variety of Illuminator Methods Available
--Sensitive Dimming System
--Safty Handle Design
--Kohler Illumination Condenser





Specifications:


A16.0907-BL Fluorescent Microscope

Head

Binocular, 30° Inclined, Interpupillary Distance 50-75mm

Eyepiece

PL10x/20mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree

Objective

Infinity Plan Achromatic 10x/0.25, 20x/0.50, 40x/0.65, 100x/1.25

Nosepiece

Backward Quadruple

Focusing

Low Position Coaxial Coarse & Fine Focusing Knob, with Safty Limitation
 and Tension Adjustment Ring. Coarse Range 25mm, Fine Precision 0.002mm

Working Stage

Double Layer Mechanical Stage 150*140mm, Moving Range 76*50mm, Precision 0.1mm

Condenser

Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed

Filter

Blue, Dia.45

Light Source

3W LED, Intensity Adjustable, Center Fixed

Fluorescent

LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent
Switch Knob, LED Wave Length 470, Band B1

Power

90~240V Wide Range Power Supply

A16.0907-B Fluorescent Microscope Optional Accessories

Head

Trinocular, 30° Inclined, Interpupillary Distance 50-75mm

A53.0907-T30R

Eyepiece

PL10x/22mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree

A51.0904-1022T

Nosepiece

Backward Quintuple

A54.0930-BS5

Fluorescent

LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent
 Switch Knob,LED Wave Length 560, Band G1

A5F.0912-G1

LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent
 Switch Knob,LED Wave Length 365, Band UV2

A5F.0912-UV2

LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent
 Switch Knob,LED Wave Length 455, Band B4
Speically Used for Tuberculosis Inspection

A5F.0912-B4

Adapter

C-Mount 1.0x, Focus Adjustable

A55.0925-1

C-Mount 0.5x, Focus Adjustable , for 1/2 CCD

A55.0925-1/2

C-Mount 0.35x, Focus Adjustable, for 1/3 CCD

A55.0925-1/3

Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece

A55.0901-1

Professional Photo C Mount, with Photo Eyepiece

A55.0910
