Industrial Inspection Metal Binocular Compound Microscope 800x , CE A13.2703

Industrial Inspection Metal Binocular Compound Microscope 800x , CE A13.2703

  • High Light

    reflected light microscope

    ,

    halogen lamp microscope

  • Certification
    CE, Rohs
  • Application
    Learning, Metallurgical
  • Drawtube
    Binocular
  • Illumination
    Multi-function Half Reflecting Device
  • Magnification
    100x - 800x
  • Theory
    Metallurgical Optical Microscope
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Model Number
    A13.2703
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Industrial Inspection Metal Binocular Compound Microscope 800x , CE A13.2703



Industrial Inspection Metal Binocular Compound Microscope 800x , CE A13.2703





Description:



Metallurgical Optical Microscope uses a different lighting method than a conventional microscope and can illuminate solid specimens to identify, inspect, and measure them. Some industries use inverted metallurgical microscopes, which observe the specimen from below the stage or table. Electronic parts manufacturers, forensic laboratories, and metal foundries all use this type of instrument.




Specifications:



Specification

A13.2703

Optical System

UCIS infinity independent achromatic optical system

Head

Seidentopf binocular head,45° inclined, interpupillary distance

52-75mm,diopter adjustable

Eyepiece

WF10x/20mm, plan, high eyepoint up to 21mm,

WF10x/20mm, plan, reticule eyepiece, diopter adjustable

Objective

Infinity plan achromatic objective 10x

Infinity plan achromatic objective 20x(s)

Infinity LWD plan achromatic objective 50x(s)

Infinity LWD plan achromatic objective 80x(s)

Focus System

Low positioned, coaxial coarse & fine focusing system with

adjustable tension control and upper limit stop, minimum reading

1μm, moving range 12mm

Nosepiece

Quintuple, reversed type with positive click stops

Stage

Right hand controls, low position, mechanical stage, size

350x208mm, moving range 50x50mm.

Drop specimen holder(φ118)

Specimen holder

Illumination

Multi-function half reflecting device

Bright field module

Filter

Blue, green, yellow

Adapter

0.5x C-Mount

Polarizing Attachment

Analyzer

Polarizer

Reflected Light

12V100W halogen lamp house,

12V 50W halogen power supply unit

12V50W halogen bulb (Osram)

250V/5A Φ5X20 fuse

Power supply 110-240V,50/60Hz

Other

Allen screw driver 2mm

Allen screw driver 2.5mm

Allen screw driver 3mm

Metallurgical micrometer(1/100mm)

Dust cover

Power cord

A13.2703 Optional Accessories

Item No.

Head

Seidentopf Binocular Head, 30° Inclined, Interpupillary Distance

48-75mm, Diopter Adjustable

A53.2702-1A

Eyepiece

WF10x/22mm, plan, high eyepoint up to 21mm

A51.2701-10C

WF16X/13mm

A51.2701-1613

Objective

Infinity plan achromatic objective 5x

A52.2706-05A

Infinity plan achromatic objective 100x

A52.2706-100A

Stage

Fixed stage, size 240x260mm,moving range 135x85mm,

low position, coaxial adjustment

A54.2706-1

Adapter

0.25x, C-Mount (suitable to 1/3" CCD)

A55.2701-25A

Digital camera adapter (need to know camera model number)

A55.2702-2

Light Source

12V 100W halogen lamp house

A56.2703-4

12V 100W halogen bulb (Osram)

A56.2703-100

250V/5A Φ5X20

A56.2703-5A

Other

Specimen presser

A5M.2713
