Bright Field Metallurgical Optical Microscope Laboratory A13.1011

Bright Field Metallurgical Optical Microscope Laboratory A13.1011

  • High Light

    reflected light microscope

    ,

    halogen lamp microscope

  • Application
    Research, Metallurgical
  • Certification
    CE, Rohs
  • Drawtube
    Binocular
  • Illumination
    Halogen Lamp
  • Theory
    Metallurgical Optical Microscope
  • Optical System
    Infinity Optical System
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A13.1011
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Bright Field Metallurgical Optical Microscope Laboratory A13.1011



Halogen Lamp Metallurgical Optical Microscope Laboratory A13.1011



Description:



A13.1011 Laboratory BF/DF Metallurigcal Microscope, is an ideal instrument for industry inspecition and science research laboratory.

Bright/Dark Field Metallurgical microscope
Full range BF/DF Objectives included
Polarization system optional
Powerful transmitted and reflected system with Kohler illumination.





Specifications:



Specification A13.1011
A
B
Optical System
Infinity optical system
Head
Seidentopf trinocular viewing head, inclined at 30°, interpupillarty distance 48mm-75mm
Eyepiece
Extra Wide Field Eyepiece EW 10x/22
Objective
Infinity Plan Achromatic Objectives, BF 5x/ 0.12/ ∞/ - (BF) ,W.D.=15.5mm
50x/ 0.75/ ∞/ 0 (BF) ,W.D.=0.32mm
100x/1.25/∞/0.17 ,W.D.=0.13mm
Infinity Plan Achromatic Objectives, BF/DF 10x/ 0.25/ ∞/ - (BF/DF) ,W.D.=10.0mm
20x/ 0.4/ ∞/ 0 (BF/DF) ,W.D.=4.30mm
Infinity Plan Achromatic Objectives 40x/0.66/∞/0.17 ,W.D.=0.54mm
100x/0.9/∞/0 (BF) ,W.D.=2.0mm
Max. Sample Height 30mm
-
50mm
-
Stage
Double layer mechanical stage 186×138mm/ 74mm×50mm
Specimen preparation plate
Slide glass
Nosepiece
Backward quintuple nosepiece
Adapter
3 BF/DF adapter
Focusing
Coaxial coarse and fine adjustment, fine division 1μm
Reflected Illumination
24V/100W Halogen light, lightness adjustable
Kohler illumination and aspherical condenser
Blue,Green,Yellow and Ground glass
Transmitted
Illumination
Swing-out condenser NA0.9/ 0.25
24V/ 100W Halogen light and aspherical condenser
Blue filter
Optional Accessories
Item No.
Objective
Infinity Plan Achromatic Objectives 5x/0.12/∞/0 (BF/DF) WD 12mm A5M.1036-5
Infinity Plan Achromatic Objectives 40x/0.6/∞/0 (BF/DF) WD 2.90mm A5M.1036-40
Infinity Plan Achromatic Objectives 50x/ 0.75/ ∞/ 0 (BF/DF) WD 0.32mm A5M.1036-50
Infinity Plan Achromatic Objectives 100x/0.8/∞/0 (BF/DF) WD 2mm A5M.1036-100
Filter
ND25 A5F.1011-25
ND6 A5F.1011-6
Polarizer Device Polarizer & Analyzer, Intergrate Device A5P.1002
Video Attachment
C Mount 1x A55.1002-10
C Mount 0.5x A55.1002-05
Photo Attachment
A55.1001
Specimen Presser
A5M.1010
