A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory

Product Details:
Place of Origin: China
Brand Name: CNOEC
Certification: CE
Model Number: A12.1018
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $1-$1000
Packaging Details: Carton
Delivery Time: 1month
Payment Terms: T/T,West Union and Paypal
Supply Ability: 10000
Detailed Product Description
Optical System: Infinity Plan Optical System Function: Bright Field, Optional Dark Field, Polarizing, Phase Contrast, Fluorescent
Eyepiece: Extra Wide Field Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm Nosepiece: Backward Quintuple Nosepiece, With Slide Slot
High Light:

opto edu trinocular biological microscope

,

22mm eyepiece trinocular biological microscope

,

opto edu microscope laboratory

Trinocular, EW10x/22mm, Quintuple, Infinity Plan Objective 4x10x40x100x, Mechanical Stage 185x142/ 55x75mm, Swingout NA0.9/0.25, Coaxial Coarse & Fine, External Halogen 6V30W, Kohler Illumation Asperical Collector, Eyepiece Adapter



A12.1018 Laboratory Biological Microscope
Optical System Infinity Plan Optical System
Function Bright Field, Optional Dark Field, Polarizing, Phase Contrast, Fluorescent
Head Seidentopf Trinocular Head, 30° Inclined, 360° Rotatable, Interpupillary 48~75mm, Left Eyepiece Tube Diopter Adjustable
Eyepiece Extra Wide Field Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm
Nosepiece Backward Quintuple Nosepiece, With Slide Slot
Objective Infinity Plan Achromatic Objective 4x,10x,40x,100x
Focusing Coaxial Coarse & Fine Adjustment, Focusing Range 24mm, Fine Division 0.001mm, Coarse Stroke 37.7mm
Working Stage Double Layer Mechanical Stage, 185*142mm, Moving Range 55*75mm
Condenser Swing Out Condenser N.A.0.9/0.25
Illumination Halogen Lamp 6V30W, External Kohler Illumination, With Asperical Collector, Brightness Adjustable
Filter Green, Blue
Adapter Trinocular Adapter + Eyepiece Tube Photo Adapter Dia.23.2mm
Optional Accessories
Head Seidentopf Binocular Head, 30° Inclined, Interpupillary 48~75mm A53.1003-7
Upgrade to Tilting Binocular Head 5°~35° A53.1005-3
Upgrade to Tilting Trinocular Head 5°~35° A53.1005-4
Eyepiece Extra Wide Field Eyepiece EW10x/20mm, Eyepiece Tube Dia.30mm A51.1003-1020
Extra Wide Field Eyepiece EW20x/12mm, Eyepiece Tube Dia.30mm A51.1003-2012
Extra Wide Field Eyepiece EW15x/16mm, Eyepiece Tube Dia.30mm A51.1003-1516
Objective Infinity Plan Achromatic Objective 20x A52.1006-20
Infinity Plan Achromatic Objective 60x A52.1006-60
Nosepiece Sextuple Nosepiece A54.1001-6
Illumination Upgrade To Halogen Lamp 24V50W, For Better Dark View A56.1018-50W
Upgrade To Halogen Lamp 24V100W, For Better Dark View A56.1018-100W
Adapter 0.45x C-Mount A55.1002-45
Dark Field Dark Field Condenser, N.A. 0.7~0.9, Dry,
Use With 40x Or Lower Magnification Objective
A5D.1010-D
Dark Field Condenser, N.A. 1.25~1.36, Immersion,
Use With 100x Objective
A5D.1010-I
Dark Field Objective, Infinity Plan 100x(Oil) A5D.1030-3
Dark Field Objective, Infinity Plan 100x(Oil), With Iris Diaphragm A5D.1030-4
Phase Contrast Infinity Plan Turret Phase Contrast Set A5C.1003-A1
--Infinity Plan Turret Phase Contrast Condenser
--Infinity Plan Phase Contrast Objective 4x,10x,40x,100x
--Centering Telescope 10x
--Green Filter
Infinity Achromatic Turret Phase Contrast Set A5C.1003-A2
--Infinity Achromatic Turret Phase Contrast Condenser
--Infinity Achromatic Phase Contrast Objective 4x,10x,40x,100x
--Centering Telescope 10x
--Green Filter
Flourescent EPI-Fluorescent Kit, Upgrade to A16.1028 A5F.1002-BG
--Power Supplier 220V/110V Interchangeable, Digital Display
--100WHBO Ultra Hi-Voltage Spherical Mercury Lamp
--Barrier To Resist Ultraviolet Light
--Fluorescence Free Oil
--Excitation Filter B/G
EPI-Fluorescent Kit, Upgrade to A16.1028 A5F.1002-BGVU
--Power Supplier 220V/110V Interchangeable, Digital Display
--100WHBO Ultra Hi-Voltage Spherical Mercury Lamp
--Barrier To Resist Ultraviolet Light
--Fluorescence Free Oil
--Excitation Filter B/G/V/U
EPI LED Fluorescent Kit, Upgrade To A16.1029
EPI Light 3W LED 465~475nm, B Excite Filter BP460~490,
A5F.1004-B
EPI Light 3W LED 525~530nm, G Excite Filter BP510~550 A5F.1004-G
Polarizing Polarizing Attachment , Polarizer, Analyzer, Intergrate Device A5P.1002







A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 0

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 1

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 2

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 3

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 4

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 5

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 6

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 7

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 8

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 9

A12.1018 OPTO-EDU Trinocular Biological Microscope Laboratory 10
