LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision

Highlight

binocular compound microscope
,
wide field microscope
Eyepiece

WF10x
Nosepiece

4 Holes
Objective

Achromatic,Achromatic Plan,Infinity EPlan,Infinity Plan 4x10x40x100x
Working Stage

Working Stage
Condenser

Abbe N.A.1.25
Focusing

Coaxial Coarse & Finem, Moving Range 75*50mm
Light Source

LED
Power Supply

100~240V
Place of Origin

China
Brand Name

CNOEC, OPTO-EDU
Certification

CE, Rohs
Model Number

A12.2601
Document

Product Brochure PDF
Minimum Order Quantity

1 pc
Price

FOB $1~1000, Depend on Order Quantity
Packaging Details

Carton Packing, For Export Transportation
Delivery Time

5~20 Days
Payment Terms

T/T, West Union, Paypal
Supply Ability

5000 pcs/ Month

LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision

Name: LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision
Brand: Opto-Edu (Beijing) Co., Ltd.
SKU: A12.2601
Price: 500.00 USD
Availability: InStock

button button

Get Price Contact Now

OPTO-EDU A12.2601-BT 400X Double Layer Mechanical Trinocualr Laboratory Metal Microscope

A12.2601 Laboratory Microscope, new design with high quality optical system, supplying clear image, is good to be used in high school, university for student. Color can be made according to customer's requirement, new concept in microscope field.

♦ Entry Level Laboratory Microscope With Full Range Upgrade Extention

♦ Can Use 40x LWD Infinity Plan Objective W.D.=3.0m To Avoid Contaminated By Cedar Oil

♦ Creative 100x Water Objective Instead Of I00x Oil Objective For Easy Use Without Oil

♦ High Rigidity Body Struction Design Supply High Steady And Easy Handle

♦ Different Color Available To Customrize Your Model!

LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 0

LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 2

Seidentopf Head
Inclined 30°,Rotatable 360°, Interpupillary Distance 48-75mm, High Eyepoint Eyepiece,

Which Is Convenient For People With Different Sitting Height; The Integrated Design Of The Eyepiece Lens Barrel,

Avoids The Loss And Contamination Of The Eyepiece And Enhances The Integrated Performance Of The Microscope
LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 3

Quadruple, Backward
4 Sets Objective Available: Achromatic, Plan, Infinity E-Plan, Infinity Plan.
LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 4

Double Slide Holder Working Stage
Mechanical Stage Size: 145 mm×140mm, Travel: 76mmX52mm, Scale: 0.1mm
LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 5

Condenser & Light Source
Abbe Condenser N.A.1.25, Iris Diaphragm, Rack & Pinion Up/Down, With Filter Holder

3W-LED Illumination Systems

LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 6

LED A12.2601-BT 400X Student Compound Microscope WF10x High Precision 10

Items	A12.2601 Biological Microscope Specification	-A	-AT	-B	-BT	-C	-CT	-D	-DT	Cata. No.
Head	Seidentopf Binocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm	●	○	●	○	●	○	●	○	A53.2621-B
Head	Seidentopf Trinocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm, Light Split Fixed P20:E80	○	●	○	●	○	●	○	●	A53.2621-T
Eyepiece	WF10x/18mm	●●	●●							A51.2602-1018
Eyepiece	WF10X/20mm (High Eyepoint)			●●	●●	●●	●●	●●	●●	A51.2602-1020
Nosepiece	Quadruple, Backward	●	●	●	●	●	●	●	●	A54.2610-N734
Nosepiece	Quintuple, Backward	○	○	○	○	○	○	○	○	A54.2610-N735
Achromatic Objective	4x/0.1, W.D.=18.6mm	●	●							A52.2601-4
	10x/0.25, W.D.=6.5mm	●	●							A52.2601-10
	20x/0.40, W.D.=1.75mm	●	●							A52.2601-20
	40x/0.6(S), W.D.=0.47mm	●	●							A52.2601-40
	60x/0.80(S), W.D.=0.10mm	○	○							A52.2601-60
	100x/1.25(S,O), W.D.=0.07mm	○	○							A52.2601-100
Plan Objective	4x/0.1, W.D.=14.5mm			●	●					A52.2603-4
	10x/0.25, W.D.=5.65mm			●	●					A52.2603-10
	20x/0.40, W.D.=5.65mm			○	○					A52.2603-20
	40x/0.6(S), W.D.=0.85mm			●	●					A52.2603-40
	100x/1.25(S,O), W.D.=0.07mm			●	●					A52.2603-100
Infinity E-Plan Objective	EPLAN 4x/0.10,W.D.=12.1mm					●	●			A52.2605-4
	EPLAN 10x/0.25,W.D.=4.14mm					●	●			A52.2605-10
	EPLAN 20x/0.4					○	○			A52.2605-20
	EPLAN 40x/0.65(S),W.D.=0.58mm					●	●			A52.2605-40
	EPLAN 100x/1.25(S, Oil),W.D.=0.19mm					●	●			A52.2605-100
Infinity Plan Objectives	PLAN 2.5x/0.07,W.D.=8.47mm							○	○	A52.2606-2.5
	PLAN 4X/0.10.W.D.=12.1mm							●	●	A52.2606-4
	PLAN 10X/0.25.W.D.=4.64mm							●	●	A52.2606-10
	PLAN 20X/0.40(S).W.D.=2.41mm							○	○	A52.2606-20
	PLAN 40X/0.66(S).W.D.=0.65mm							●	●	A52.2606-40
	PLAN 60X/0.80(S).W.D.=0.33mm							○	○	A52.2606-60
	PLAN 100X/1.25(S,Oil).W.D.=0.12mm							●	●	A52.2606-100
	PLAN 100X/1.15(S,Water).W.D.=0.19mm							○	○	A52.2606-100W
Working Stage	Mechanical Stage Size: 145 mm×140mm, Travel: 76mmX52mm, Scale: 0.1mm, Double Slide Holder	●	●	●	●	●	●	●	●	A54.2601-S04
Working Stage	Rackless (Integrated) Stage, Size 140×135mm, Travel Range 75×35mm, Double Slide Holder	○	○	○	○	○	○	○	○	A54.2601-S12
Focusing	Coaxial Coarse & Fine Focusing, Coarse Focusing Travel Range: 26mm, Fine Focusing Travel Range: 2µm/Division	●	●	●	●	●	●	●	●
Condenser	Abbe Condenser N.A.1.25, Iris Diaphragm, Rack & Pinion Up/Down, With Filter Holder	●	●	●	●	●	●	●	●	A56.2614-C06b
Illumination	3W-LED Illumination Systems Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use	●	●	●	●	●	●	●	●	A56.2613-3W
	12V/20W Halogen Lamp, Power Supply Wide Voltage 100V~240V	○	○	○	○	○	○	○	○	A56.2650-20W
	6V/30W Halogen Lamp, Power Supply Wide Voltage 100V~240V	○	○	○	○	○	○	○	○	A56.2650-30W
Field Diaphragm	Upgrade To Kohler Illumnation	○	○	○	○	○	○	○	○	A56.2615-S
Filter	Dia.45mm, Blue	○	○	○	○	○	○	○	○	A56.2616-45B
	Dia.45mm, Green	○	○	○	○	○	○	○	○	A56.2616-45G
	Dia.45mm, Yellow	○	○	○	○	○	○	○	○	A56.2616-45A
Dark Field	Dark Field Condenser, Dry, N.A.0.83-0.91, For 4x10x40x Objective	○	○	○	○	○	○	○	○	A5D.2610-S
Polarizing	Analyzer + Polarizer Set	○	○	○	○	○	○	○	○	A5P.2601-S
Phase Contrast	Infinity Plan Phase Contrast Objective 10x + Phase Contrast Slide 10x + Phase Contrast Condenser + Telescope 11x + Green Filter	○	○	○	○	○	○	○	○	A5C.2601-10
	Infinity Plan Phase Contrast Objective 20x + Phase Contrast Slide 20x + Phase Contrast Condenser + Telescope 11x + Green Filter	○	○	○	○	○	○	○	○	A5C.2601-20
	Infinity Plan Phase Contrast Objective 40x + Phase Contrast Slide 40x + Phase Contrast Condenser + Telescope 11x + Green Filter	○	○	○	○	○	○	○	○	A5C.2601-40
	Infinity Plan Phase Contrast Objective 100x + Phase Contrast Slide 100x + Phase Contrast Condenser + Telescope 11x + Green Filter	○	○	○	○	○	○	○	○	A5C.2601-100
	Turret Phase Contrast Attachment Infinity Plan Phase Contrast Objective 10x20x40x100x, Turret Phase Contrast Condenser 5-Holes, Telescope 11x, Green Filter	○	○	○	○	○	○	○	○	A5C.2603-S
Fluorescence Unit	Upgrade to A16.2601-B2/T2 Fluorescence Microscope With: B,G China Fluorescent Set 100W Mercury Lamp House 100W Mercury Power Box, Digital Disp. 6 Holes Disc Fluorescent Unit Ultraviolet Protection Barrier Centering Objective China 100W Mercury Lamp 2 pcs					○	○			A5F.2601-2
	Upgrade to A16.2601-B4/T4 Fluorescence Microscope With: B,G,U,UV China Fluorescent Set 100W Mercury Lamp House 100W Mercury Power Box, Digital Disp. 6 Holes Disc Fluorescent Unit Ultraviolet Protection Barrier Centering Objective China 100W Mercury Lamp 2 pcs					○	○			A5F.2601-4
	Upgrade to A16.2601-LB2/LT2 Fluorescence Microscope With: B,G China Fluorescent Set 6 Holes Disc Fluorescent Unit 5W LED Lamp House 5W LED Power Box Ultraviolet Protection Barrier					○	○			A5F.2602-2
	Upgrade to A16.2601--LB4/LT4 Fluorescence Microscope With: B,G,U,UV China Fluorescent Set 6 Holes Disc Fluorescent Unit 5W LED Lamp House 5W LED Power Box Ultraviolet Protection Barrier					○	○			A5F.2602-4
Adapter	C-Mount 0.5x, Focus Adjustable	○	○	○	○	○	○	○	○	A55.2601-05
	C-Mount 0.75x, Focus Adjustable	○	○	○	○	○	○	○	○	A55.2601-75
	C-Mount1.0x, Focus Adjustable	○	○	○	○	○	○	○	○	A55.2601-10
	Digital Eyepiece Camera Adapter, Dia. 23.2mm/25mm	○	○	○	○	○	○	○	○	A55.2610
Mirror	Reflecting Mirror & Holder	○	○	○	○	○	○	○	○	A56.2601
Attachment	Wire Winding Device	○	○	○	○	○	○	○	○	A50.2602-S
Package	Carton Size 390×280×450mm, 1 Unit/Ctn
Weight	Gross Weight: 7.5 kgs, Net Weight: 6.5 kgs
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories
