Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B

Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B

  • High Light

    high powered microscope

    ,

    binocular biological microscope

    ,

    biological compound microscope

  • Total Magnification
    40X~1000X
  • Eyepiece
    WF10X
  • Head
    Compensation Free Binocular,30° Inclined,360° Rotatable
  • Objectives
    4x,10x,40x,100x
  • Nosepiece
    Quadruple
  • Focusing
    Coaxial Coarse And Fine Focus Adjustment, Range:22mm
  • Stage
    Double Layer Mechanical Stage 125mmx115mm, Moving Range : 75mmx35mm
  • Condenser
    ABBE NA1.25 Condenser
  • Illuminator
    3W LED
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE, Rohs
  • Model Number
    A11.2601
  • Minimum Order Quantity
    1 pc
  • Price
    Negotiation
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B

Monocular Trinocular Educational Gift Cheap Binocular Optical School Student Microscope
Wide Field Eyepiece WF10x/18mm

High Contrast Achromatic Objective 4x,10x,40x,100x

Mechanical Stage 115x125mm, Moving Range 70x35mm

Full Metal Body High Rigid Construction

3W LED, Cordless Rechargeable Function Optional



A11.2601 Biological Microscope Is
Designed For Teaching, Clinical Verify.
The Series Microscope With Original Style,
Steady Structure, Convenient Operation
And Clear Image Is Suitable For Observing
Various Biological Specimens, And Mostly
Applied In School, College, Hospital And Family.



OPTO-EDU has our own factory for high end laboratory, polarizing, metallurgical, fluorescence microscope CNOPTEC series, for comparison microscope A18 series, for SEM microscope A63 series, and for digital camera & LCD camera.

Meantime, we are one of the best supplier for all kinds & levels microscope & accessoreis made in China, working in this field for more than 25 years, we have more than 1200 microscopes models, and 5000 educational instrument to serve our customer with full range products.

Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B 0

Head
WF10x-18mm, Eyepiece Is Anti-fungal, Anti-fungal System Built In Head
Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B 1

Objective
Achromatic Objective: 4x, 10x, 40x(s), 100x/1.25(oil)(s), Objective Is Anti-fungal
Working Stage
Mechanical Stage, Stage Size:125mm×115mm,Travel: 35mm×75mm
Abbe Condenser
N.A. 1.25, Adjustable Aperture, Aperture Center Is Adjustable, Built In Blue Filer, ф38.5mm
Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B 2

Focus
Coaxial Coarse & Fine Focus, Stage Moving Knob Can Move Stage Turn Left Or Right
Light Source
LED Illumination Systems (Non-rechargeable), Rotation Potentiometer With Power Switch

Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B 3

A11.2601 Student Biological Microscope Upgrade To A13.2603 Metallurgical Microscope
A13.2603 Metallographic microscopes are often used to observe opaque objects such as wafers

Binocular Optical School Student Microscope Monocular Trinocular Educational Gift A11.2601-B 4

Powered By Safety Low Voltage Charger
Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use

Items A11.2601 Student Biological Microscope Specification -M -B -T -BP -TP Cata. No.
Head Monocular Head Inclined 30°, Rotatable 360°         A53.2601-M
Seidentopf Binocular Head Inclined 30°, Rotatable 360°, Interpupilary Distance 48-75mm       A53.2601-B
Seidentopf Trinocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm, Light Split Fixed P20/E80       A53.2601-T
Eyepiece WF10x/18mm ●● ●● ●● ●● A51.2602-1018
WF16x/13mm A51.2602-1613
WF10x/18mm With Pionter A51.2604-1018
WF10x/18mm, With Micrometer X-0.1mm*180 Div / Y-Single Line A51.2605-1018
WF10x/18mm With Micrometer X-0.1mm*180 Div / Y-Single Line, Diopter Adjustable A51.2605-1018D
Nosepiece Quadruple, Backward A54.2610-N03
Achromatic Objective 4x/0.1, W.D.=18.6mm     A52.2601-4
10x/0.25, W.D.=6.5mm     A52.2601-10
20x/0.40, W.D.=1.75mm     A52.2601-20
40x/0.6(S), W.D.=0.47mm     A52.2601-40
60x/0.80(S), W.D.=0.10mm     A52.2601-60
100x/1.25(S,O), W.D.=0.07mm     A52.2601-100
Plan
Objective
4x/0.1, W.D.=14.5mm       A52.2603-4
10x/0.25, W.D.=5.65mm       A52.2603-10
20x/0.40, W.D.=5.65mm       A52.2603-20
40x/0.6(S), W.D.=0.85mm       A52.2603-40
100x/1.25(S,O), W.D.=0.07mm       A52.2603-100
Stage Double Layer Mechanical Size 125×115mm,
Travel Range 35×75mm
A54.2601-S03
Condenser Abbe N.A. 1.25(Iris Diaphragm) A56.2614-09
Focusing Coaxial Coarse And Fine Focusing Knobs,
Travel Range: 22mm, Scale: 2µm

C-mount 1.0x (Focus Adjustable)       A55.2601-B10
0.5x (Focus Adjustable)       A55.2601-B05
Light Source 3W LED Illumination, Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use A56.2613-3W
3W LED Illumination (Rechargeable), Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use A56.2651-3WR
12V 20W Halogen Lamp, Wide Voltage: 100V-240V A56.2650-20W
Plano-Concave Mirror A56.2601-B
Dark Field Dark Field Ring, For 4x~40x Objective A5D.2611-B
Polarizing Analyzer + Polarizer Set A5P.2601-B
Package Carton Size 337*242*417mm, 1 Unit/Ctn
Weight Gross Weight 7.0kgs, Net Weigth 5.5kgs
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
